Vrla Lead Acid Storage Battery , Electrolyte Gel Cell Motorcycle Battery
Vrla Lead Acid Storage Battery , Electrolyte Gel Cell Motorcycle Battery
Lead Acid Storage Battery Applications:
- Water pumping system,
- Portable power supply,
- Small town power system,
- Control systems, Electric toys, Emergency lamp, Power tools,
- Medical treatment equipment, Alarm system, Emergency light system,
- Standby power supply, UPS and computer standby power supply,
- Telecommunication system, Firefighting equipment standby power supply, Railway station, Ship Equipment, Military Equipment,
- Telephone switching system.
Lead Acid Storage Battery Features
1. This stationary battery comes with a superior gel electrolyte where sulfuric acid is evenly mixed with silica fume and acid layering does not exist.
2. The electrolyte is gel like and immobile, which enables no leakage and uniform reaction of battery plates.
3. Serving as perfect power supply equipment, the front access lead acid battery is designed with slim shape. Front access terminal connection is convenient for installation and maintenance, and space serving.
4. Radial type grid design and tight assembly technology enable prominent high rate discharge performance for our GEL VRLA battery.
Lead Acid Storage Battery Specifications:
|
Model |
Voltage |
Capacity |
Dimension(mm) |
Terminal |
Weight |
|||
|
(V) |
(Ah) |
L |
W |
H |
TH |
Type |
(Kg±3%) |
|
|
6FM50G |
12 |
50 |
229 |
138 |
211 |
214 |
F14 |
14 |
|
6FM55G |
12 |
50 |
229 |
138 |
211 |
214 |
F14 |
15 |
|
6FM70G |
12 |
70 |
260 |
168 |
211 |
214 |
F14 |
21.5 |
|
6FM65G |
12 |
65 |
350 |
167 |
179 |
179 |
F14 |
20 |
|
6FM90G |
12 |
90 |
306 |
169 |
211 |
214 |
F14 |
27 |
|
6FM100G |
12 |
100 |
330 |
171 |
214 |
220 |
F14 |
29.5 |
|
6FM120AG |
12 |
120 |
409 |
176 |
225 |
225 |
F13 |
34 |
|
6FM120G |
12 |
120 |
406 |
173 |
208 |
238 |
F13 |
34 |
|
6FM150G |
12 |
150 |
485 |
172 |
240 |
240 |
F13 |
43 |
|
6FM160G |
12 |
160 |
530 |
207 |
210 |
213 |
F13 |
47.5 |
|
6FM180G |
12 |
180 |
52.5 |
|||||
Lead Acid Storage Battery Advantage:
- Ideal for cyclic uses
- Good tolerance to higher temperature applications.
- ABS containers and covers(UL94HB, UL94V-0) optional.
- Safety valve installation for explosion proof.
- Higher safety & reliable construction.
- Extra durability and deep cycle ability for heavy demand applications.
- Low self discharge characteristic.
