Industrial Maintenance Free Lead Acid Battery , Sulfuric Acid Battery
Industrial Maintenance Free Lead Acid Battery , Sulfuric Acid Battery
Maintenance Free Lead Acid Battery Features:
Sealed and maintenance free operation.
Non-Spillable construction design.
ABS containers and covers(UL94HB, UL94-0)optional.
Safety valve installation for explosion proof.
High quality and high reliability.
Exceptional deep discharge recovery performance.
Low self discharge characteristic.
Flexibility design for multiple install positions.
Maintenance Free Lead Acid BatteryAdvantage:
Special grid alloy for deep cycle use
First class ABS container
Top lead of purity 99.994%
Low self-discharge
Long service life
Manufacture with more than 10 years history
Maintenance Free Lead Acid Battery Applications:
|
1. Solar system |
2. Solar power stations |
3. Pump systems |
|
4. Telecommunications installations |
5. Measurement stations |
6. Boats or buoys |
|
7. Signal station |
8. Survey and Mapping system |
9. Emergency lighting |
|
10. Caravans |
11. Traffic lights |
12. Street lightening |
Maintenance Free Lead Acid Battery Specifications:
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Weight | |||
| (V) | (Ah) | L | W | H | TH | Type | (Kg±2%) | |
| 3FM100G | 6 | 100 | 194 | 170 | 205 | 210 | M8 | 15.5 |
| 3FM150G | 6 | 150 | 260 | 180 | 245 | 250 | M8 | 23 |
| 3FM180G | 6 | 180 | 307 | 169 | 220 | 225 | M8 | 27 |
| 3FM200G | 6 | 200 | 321 | 176 | 226 | 229 | M8 | 29.5 |
| 3FM300G | 6 | 300 | 295 | 178 | 345 | 348 | M8 | 47 |
| 4FM180G | 8 | 180 | 260 | 182 | 295 | 298 | M8 | 36.5 |
| 6FM33G | 12 | 33 | 195 | 130 | 155 | 166 | M6 | 10 |
| 6FM40G | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 12.5 |
| 6FM42G | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 13.5 |
| 6FM50G | 12 | 50 | 229 | 138 | 211 | 214 | M6 | 15.5 |
| 6FM55G | 12 | 50 | 229 | 138 | 205 | 210 | M6 | 16.5 |
| 6FM70G | 12 | 70 | 260 | 168 | 211 | 214 | M6 | 21.5 |
| 6FM75G | 12 | 70 | 260 | 168 | 211 | 214 | M6 | 22.5 |
| 6FM60G | 12 | 65 | 350 | 167 | 179 | 179 | M6 | 19.5 |
| 6FM65G | 12 | 65 | 350 | 167 | 179 | 179 | M6 | 20.5 |
| 6FM90G | 12 | 90 | 306 | 169 | 211 | 214 | M6 | 27 |
| 6FM100G | 12 | 100 | 330 | 171 | 214 | 220 | M8 | 30 |
| 6FM120G | 12 | 120 | 406 | 173 | 208 | 238 | M8 | 34 |
| 6FM134G | 12 | 120 | 340 | 172 | 282 | 284 | M8 | 42 |
| 6FM140G | 12 | 120 | 340 | 172 | 282 | 284 | M8 | 42.5 |
| 6FM150G | 12 | 150 | 485 | 172 | 240 | 240 | M8 | 43 |
| 6FM160G | 12 | 160 | 530 | 207 | 210 | 213 | M8 | 47.5 |
| 6FM180G | 12 | 180 | M8 | 52.5 | ||||
| 6FM200G | 12 | 200 | 522 | 238 | 218 | 221 | M8 | 60 |
| 6FM250G | 12 | 250 | 521 | 269 | 220 | 223 | M8 | 71 |
Competitive Advantage:
Special grid alloy for deep cycle use
Long service life
Manufacture with more than 10 years history
Capable of high discharge rates
Low self-discharge
