Industrial Lead Acid Storage Battery , Lead Acid Gel Cell Batteries

Product Name

12v 9ah battery

 Capacity
(25°C)

20HR(10.5V)

9Ah

10HR(10.5V)

8.4Ah

1HR(9.60V)

5.8Ah



Dimension

Length

151±1.5mm (5.94inch)

Width

65±1mm (2.56inch)

Height

94±1mm (3.70inch)

Total Height

100±1mm (3.94inch)

Approx. Weight

2.5kg

Terminal type

F1/F2

Internal resistance
(Fully charged, 25°C)

Approx. 19mΩ


Capacity affected by temperature (20HR)

40°C

102%

25°C

100%

0°C

85%

-15°C

65%


Self-discharge
(25°C)

3 month

Remaining Capacity: 91%

6 month

Remaining Capacity: 82%

12 month

Remaining Capacity: 65%

Nominal operating
temperature

25°C±3°C(77°F±5°F)

Operating temperature range

Discharge

-15°C~50°C(5°F~122°F)

Charge

-10°C~50°C(14°F~122°F)

Storage

-20°C~50°C(-4°F~122°F)


Float charging voltage(25°C)

13.60 to 13.80V
Temperature compensation:
-18mV/°C


Cyclic charging voltage(25°C)

14.50 to 14.90V
Temperature compensation:
-30mV/°C

Maximum charging current

2.7A

Terminal material

Copper

Maximum discharge current

135A(5 sec.)

Designed floating life(20°C)

3~5 years
