Powerful 12v 14ah Inverter Batteries Lead Acid Deep Cycle High Capacity
Powerful 12v 14ah Inverter Batteries Lead Acid Deep Cycle High Capacity
Inverter Batteries Applications:
Uninterruptible power supplies; Golf cart, Electric vehicle; Electric powered bicycle and wheelchairs; Marine equipment; Communication equipment; Power tools; Solar powered systems; Telecommunication systems; Fire & security systems,Inverter power system
Inverter Batteries Specifications:
|
Cells per Unit |
6 |
|
Normal Voltage |
12V |
|
Capacity |
14Ah@20Hr-rate to 1.75V per cell@25℃ |
|
Weight |
Approx.(3.4 ±3)%kg |
|
Maximum Discharge Current |
125A(5sec) |
|
Internal Resistance |
Approx. 17mΩ full charged @25℃ |
|
Operating Temperature Range |
Discharge: -20℃~60℃ Charge: 0℃~50℃ Storage: -20℃~60℃ |
|
Nominal Operating Temperature Range |
25℃±3℃ |
|
Float Charging Voltage |
13.7~13.9VDC/unit Average @25℃ |
|
Maximum Charging Current |
4A |
|
Equalization and Cycle Service |
14.4V~15.0VDC/unit Average @ 25℃ |
|
Self Discharge |
Self-discharge ratio less than 3%per month at 25℃. |
|
Terminal |
F2(0.250) |
|
Container Material |
ABS(UL94-HB) *Flammability resistance of (UL94-V0) can be available upon request |
Inverter Batteries Advantage:
- Professional and global manufacturer in Sealed lead-acid battery with over than 15 years experience.
- Competitive price with reliable quality.
- Fast delivery and leading time.
- OEM acceptable but same price
