High Safety AGM Lead Acid Battery 12V 200AH With Vent Valve Design
High Safety AGM Lead Acid Battery 12V 200AH With Vent Valve Design
Lead Acid Battery 12V 200AH Applications:
|
1. Solar system |
2. Solar power stations |
3. Pump systems |
|
4. Telecommunications installations |
5. Measurement stations |
6. Boats or buoys |
|
7. Signal station |
8. Survey and Mapping system |
9. Emergency lighting |
|
10. Caravans |
11. Traffic lights |
12. Street lightening |
|
13. wind power system |
14. Street signs |
15. SOS pillars |
Lead Acid Battery 12V 200AH Specifications:
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Weight | |||
| V | (Ah) | L | W | H | TH | Type | (Kg±2%) | |
| 3FM100G | 6 | 100 | 194 | 170 | 205 | 210 | M8 | 15.5 |
| 3FM150G | 6 | 150 | 260 | 180 | 245 | 250 | M8 | 23 |
| 3FM180G | 6 | 180 | 307 | 169 | 220 | 225 | M8 | 27 |
| 3FM200G | 6 | 200 | 321 | 176 | 226 | 229 | M8 | 29.5 |
| 3FM300G | 6 | 300 | 295 | 178 | 345 | 348 | M8 | 47 |
| 4FM180G | 8 | 180 | 260 | 182 | 295 | 298 | M8 | 36.5 |
| 6FM33G | 12 | 33 | 195 | 130 | 155 | 166 | M6 | 10 |
| 6FM40G | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 12.5 |
| 6FM42G | 12 | 40 | 197 | 165 | 170 | 170 | M6 | 13.5 |
| 6FM50G | 12 | 50 | 229 | 138 | 211 | 214 | M6 | 15.5 |
| 6FM55G | 12 | 50 | 229 | 138 | 205 | 210 | M6 | 16.5 |
| 6FM70G | 12 | 70 | 260 | 168 | 211 | 214 | M6 | 21.5 |
| 6FM75G | 12 | 70 | 260 | 168 | 211 | 214 | M6 | 22.5 |
| 6FM90G | 12 | 90 | 306 | 169 | 211 | 214 | M6 | 27 |
| 6FM100G | 12 | 100 | 330 | 171 | 214 | 220 | M8 | 30 |
| 6FM120G | 12 | 120 | 406 | 173 | 208 | 238 | M8 | 34 |
| 6FM140G | 12 | 120 | 340 | 172 | 282 | 284 | M8 | 42.5 |
| 6FM160G | 12 | 160 | 530 | 207 | 210 | 213 | M8 | 47.5 |
| 6FM180G | 12 | 180 | M8 | 52.5 | ||||
| 6FM200G | 12 | 200 | 522 | 238 | 218 | 221 | M8 | 60 |
Lead Acid Battery 12V 200AH Advantage:
Top lead of purity 99.994%
Very good recover ability
Long service life
Manufacture with more than 10 years history
Capable of high discharge rates
Low self-discharge
