Low Self Discharge 6V Lead Acid Battery 7ah For Security And Alarm System

6V Lead Acid Battery Specifications:

Model: 3FM7

Nominal voltage: 6V

Rated capacity: 7.0Ah /20 hour rate

Dimension: 151*34*94*99 mm

Net Weight: 1.15 Kg±0.02Kg

Terminal Type: F1/F2

Quantity per 20FT: About 17,000 PCS

6V Lead Acid Battery Applications:

1) Communication Systems: Switch, Microwave Stations, Mobile Base Stations, Data Centers, Radio and Broadcasting Stations
2) Motivity Field: Robots, Electric Toys, Electric Tools & Portable Vacuum Cleaners
3) Solar & Wind Power Generation Systems

6V Lead Acid Battery Parameters

Model	Voltage	Capacity	Dimension(mm)				Terminal	Terminal	Weight
	(V)	(Ah)	L	W	H	TH	Type	Position	(Kg±5%)
3FM1.2	6	1.2	97	24	52	58	F1	6	0.29
3FM2.3	6	2.3	43	37	76	76	/	/	0.34
3FM2.8	6	2.8	66	33	97	104	F1	4	0.50
3FM3	6	3.0	66	33	97	104	F1	4	0.57
3FM3.2	6	3.2	134	35	61	67	F1	6	0.65
3FM3.5S	6	3.5	70	47	101	107	F1	4	0.62
3FM2.5	6	2.5	70	47	101	107	F2	4	0.56
3FM4E	6	4.0	70	47	101	107	F1	4	0.66
3FM4	6	4.0	70	47	101	107	F1	4	0.68
3FM4.2	6	4.2	70	47	101	107	F1	4	0.71
3FM4.5	6	4.5	70	47	101	107	F1	4	0.75
3FM5	6	5.0	70	47	101	107	F1	4	0.80
3FM6.5	6	6.5	151	34	94	100	F1/F2	6	1.05
3FM7	6	7.0	151	34	94	100	F1/F2	6	1.10
3FM7.2	6	7.2	151	34	94	100	F1/F2	6	1.15
3FM7.5	6	7.5	151	34	94	100	F1/F2	6	1.18
3FM8	6	8.0	99	58	109	113	F1	6	1.00
3FM9	6	9.0	151	34	94	100	F1/F2	6	1.30
3FM10	6	10.0	151	50	94	100	F1/F2	6	1.55
3FM10H	6	10.0	151	50	94	100	F1/F2	6	1.65
3FM12E	6	12.0	151	50	94	100	F1/F2	6	1.70
3FM12	6	12.0	151	50	94	100	F1/F2	6	1.75
3FM12H	6	12.0	151	50	94	100	F1/F2	6	1.80
3FM20	6	20.0	157	83	125	130	F17	6	3.00
3FM36	6	36	162	88	164	170	F2	5	5.5
3FM42	6	42							6.1
3FM100	6	100	194	170	205	210	M8	4	15.5
3FM300	6	300	295	178	345	348	M8	5	47

First class ABS container

Top lead of purity 99.994%

Long service life

Manufacture with more than 15 years history

6V Lead Acid Battery Packaging
