200ah OPzS Battery
2v 200ah OPzS Battery
2v 200ah OPzS Battery Description:
Opzs Series Lead Acid batteries are designed with a combination of die-casting Tubular positive framework
and superfluous electrolyte technologies to offer a very high lever of reliability and a long service life.
Opzs batteries used special filter and proof design to ensure no acid fog runs over and burning proof,
and also convenient examine and maintenance.
General Features
1. Positive plate: It is a tubular plate that can prevent the active material from falling off. The grid of positive plate is Pb-Sb multi-alloy.
2. Separator: With the combined application of porous rubber and porous PVC, the separator has a high porosity and good corrosion-resistance.
3. Acid-proof bolt: It is of a special shape of funnel having the function of filtering acid smog and retarding flame. It can measure the density and temperature of electrolyte.
2v 200ah OPzS Battery Applications:
Power plant
UPS
Railroad Utility
Electric Utility
2v 200ah OPzS Battery Specifications:
|
Model |
Voltage |
Capacity |
Dimension(mm) |
Terminal |
Terminal |
Weight ±3%(Kg) |
|||||
|
(V) |
(Ah) |
L |
W |
H |
TH |
Type |
Position |
Dry |
Wet |
Acid |
|
|
OPzS 200 |
2 |
200 |
103 |
206 |
355 |
410 |
F12 |
7 |
13 |
17.5 |
4.5 |
|
OPzS 250 |
2 |
250 |
124 |
206 |
355 |
410 |
F12 |
7 |
15 |
20.5 |
5.5 |
|
OPzS 300 |
2 |
300 |
145 |
206 |
355 |
410 |
F12 |
7 |
17.5 |
24 |
6.5 |
|
OPzS 350 |
2 |
350 |
124 |
206 |
471 |
526 |
F12 |
7 |
21 |
28 |
7 |
|
OPzS 420 |
2 |
420 |
145 |
206 |
471 |
526 |
F12 |
7 |
23 |
32 |
9 |
|
OPzS 490 |
2 |
490 |
166 |
206 |
471 |
526 |
F12 |
7 |
26.5 |
37.5 |
11 |
|
OPzS 600 |
2 |
600 |
145 |
206 |
646 |
701 |
F12 |
7 |
35 |
47 |
12 |
|
OPzS 800 |
2 |
800 |
191 |
210 |
646 |
701 |
F12 |
8 |
48 |
64 |
16 |
|
OPzS 1000 |
2 |
1000 |
233 |
210 |
646 |
701 |
F12 |
8 |
58 |
78 |
20 |
|
OPzS 1200 |
2 |
1200 |
275 |
210 |
646 |
701 |
F12 |
8 |
68 |
92 |
24 |
|
OPzS 1500 |
2 |
1500 |
275 |
210 |
796 |
851 |
F12 |
8 |
80 |
111 |
31 |
|
OPzS 2000 |
2 |
2000 |
397 |
212 |
772 |
827 |
F12 |
12 |
110 |
152 |
42 |
|
OPzS 2500 |
2 |
2500 |
487 |
212 |
772 |
827 |
F12 |
9 |
132 |
185 |
53 |
|
OPzS 3000 |
2 |
3000 |
576 |
212 |
772 |
827 |
F12 |
9 |
159 |
222 |
63 |
Competitive Advantage:
Maintenance convenience;
Non-Spillable construction design;
Transparent containers, convenient to observe;
Special filter installation for acid fog proof;
High quality and high reliability;
Super long service life;
Special pole sealed technology;
Super reliability.
Charging and handling of Champion Batteries as below:
-
Never charge the battery in a sealed container.
-
Never disassemble the battery.
-
Never short-circuit battery terminals.
-
Never incinerate batteries, for they may explode.
-
Do not press and/or bend the terminals, or overheat them.
-
Do not mix old and new batteries together, neither use batteries of different types or brands.
-
Do not dispose of with household waste.
-
Be sure to use the specified charger for battery, and follow the charging instructions correctly.
-
Be sure to charge the batteries between the temperatures0oC/32oF to 45oC/113oF.
-
Be sure to position batteries securely, protecting them from abnormal shocks and /or vibration.
-
Be sure to keep sufficient space between batteries for ventilation (where possible>10mm).
-
Be sure to install batteries in a cool and well ventilated place.
-
The surrounding temperature must remain between-20oC/4oFto 40oC/104oF during storage.
-
Recharge the batteries at least every 6 months during storage.
Be sure to consult Champion engineers any time you are to use VRLA batteries .
