6V 300Ah Deep Cycle Lead Acid Battery Sealed M8 Terminal For UPS Inverter
6V 300Ah Deep Cycle Lead Acid Battery Made in China
Champion supply our customers reliable products with high quality and competitive price, since we have our own Lead mine & smelter factory & plate factory & SLA battery assembling factory, the purity quotient of our lead is99.994%.
Features:
Deep cycle plates design
Valve Regulated Construction (Sealed)
Safety and Automatic Valve System
Heavy Duty Grids
Float Service life of battery
Operation in any position
Wide Operation Temperature Range from -20 to 60 ℃
Flame retardant ABS material for the battery case V0 standard for option
Detailed Product Description
deep cycle 6v300ah agm Storage Battery
Application:
1. Telecommunication system
2. Uninterruptible Power Supplies (UPS)
3. Communication power supply
4. Emergency power systems
5. Auto control system
6. Inverter backup system
7. Backup power
Advantage:
1. The battery is full of power when it’s out of factory, no need to use liquid charge;
2. the use of lead-calcium alloys, battery self-discharge is very low,
3. by high partition, adsorption and strong;
4. there is no flowing liquid (poor liquid), does not leak acid and any position to use.
5. comply with environmental requirements, ease of use,
6. no memory, no need to discharge battery use, suitable for circuit design;
7. easy storage, less maintenance;
8. using ABS plastic shell and valve technology for safe use.
Specifications:
| Place of Origin: |
China
|
Brand Name: |
CHAMPION
|
Model Number: |
3FM300D
|
| Usage: |
Sweeper / golf cart
|
Voltage: |
6V
|
Sealed Type: |
Sealed
|
| Maintenance Type: |
Free
|
Size: |
295*180*370
|
Weight: |
47Kg
|
| Nominal Capacity: |
300AH
|
Material: | deep cycle |
and the range of all models :
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Terminal | Weight | |||
| (V) | (Ah) | L | W | H | TH | Type | Position | (Kg±5%) | |
| 6FM7D | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.15 |
| 6FM12D | 12 | 12.0 | 151 | 98 | 95 | 101 | F2/F1 | 1 | 3.45 |
| 6FM18D | 12 | 18.0 | 181 | 77 | 167 | 167 | F17/F18 | 3 | 5.25 |
| 6FM24D | 12 | 24.0 | 166 | 175 | 125 | 125 | F17/F18 | 3 | 7.4 |
| 3FM100D | 6 | 100 | 194 | 170 | 205 | 210 | F14 | 4 | 15.5 |
| 3FM150D | 6 | 150 | 260 | 180 | 245 | 250 | F13 | 5 | 23 |
| 3FM180D | 6 | 180 | 307 | 169 | 220 | 225 | F13 | 5 | 27 |
| 3FM200D | 6 | 200 | 321 | 176 | 226 | 229 | F13 | 4 | 29.5 |
| 3FM300D | 6 | 300 | 295 | 178 | 345 | 348 | F13 | 5 | 47 |
| 4FM180D | 8 | 180 | 260 | 182 | 295 | 298 | F13 | 6 | 36.5 |
| 6FM33D | 12 | 33 | 195 | 130 | 155 | 166 | F14 | 6 | 10 |
| 6FM40D | 12 | 40 | 197 | 165 | 170 | 170 | F14 | 3 | 12.5 |
| 6FM50D | 12 | 50 | 229 | 138 | 211 | 214 | F14 | 6 | 15.5 |
| 6FM50AD | 12 | 50 | 229 | 138 | 205 | 210 | F14 | 6 | 15.5 |
| 6FM70D | 12 | 70 | 260 | 168 | 211 | 214 | F14 | 6 | 21.5 |
| 6FM65D | 12 | 65 | 350 | 167 | 179 | 179 | F14 | 6 | 20 |
| 6FM90D | 12 | 90 | 306 | 169 | 211 | 214 | F14 | 6 | 27 |
| 6FM100D | 12 | 100 | 330 | 171 | 214 | 220 | F14 | 6 | 29.5 |
| 6FM120AD | 12 | 120 | 409 | 176 | 225 | 225 | F13 | 6 | 34 |
| 6FM120D | 12 | 120 | 406 | 173 | 208 | 238 | F13 | 6 | 34 |
| 6FM150D | 12 | 150 | 485 | 172 | 240 | 240 | F13 | 6 | 43 |
| 6FM160D | 12 | 160 | 530 | 207 | 210 | 213 | F13 | 2 | 47.5 |
| 6FM180D | 12 | 180 | 52.5 | ||||||
| 6FM200D | 12 | 200 | 522 | 238 | 218 | 221 | F13 | 2 | 59.5 |
| 6FM250D | 12 | 250 | 521 | 269 | 220 | 223 | F13 | 2 | 71 |
| GFM100D | 2 | 100 | 171 | 72 | 205 | 210 | F13 | 7 | 5.6 |
| GFM150D | 2 | 150 | 171 | 102 | 206 | 221 | F13 | 4 | 8 |
| GFM200D | 2 | 200 | 171 | 111 | 330 | 364 | F12 | 7 | 12.8 |
| GFM300D | 2 | 300 | 171 | 151 | 330 | 364 | F12 | 7 | 18 |
| GFM400D | 2 | 400 | 210 | 175 | 330 | 367 | F12 | 8 | 25 |
| GFM500D | 2 | 500 | 241 | 175 | 330 | 365 | F12 | 8 | 30 |
| GFM600D | 2 | 600 | 302 | 175 | 330 | 367 | F12 | 8 | 36 |
| GFM800D | 2 | 800 | 410 | 175 | 330 | 367 | F12 | 9 | 50 |
| GFM1000D | 2 | 1000 | 475 | 175 | 330 | 367 | F12 | 9 | 60 |
| GFM1500D | 2 | 1500 | 400 | 350 | 345 | 382 | F12 | 10 | 93 |
| GFM2000D | 2 | 2000 | 490 | 350 | 345 | 382 | F12 | 11 | 120 |
| GFM3000D | 2 | 3000 | 710 | 350 | 345 | 382 | F12 | 11 | 180 |
Competitive Advantage:
Excellent cyclic life range
Manufacture with more than 22 years history
Capable of high discharge rates
Best cost performance
First class ABS container
Low self-discharge
Long service life with good performance of DOD discharge
Top lead of purity 99.994%
