Inverter Deep Cycle Sealed Lead Acid Battery 12V Sealed AGM Battery
6FM60 Inverter And Solar Batteries 12 Volt 60ah Deep Cycle Lead Acid Sealed AGM Battery
Description:
| Place of Origin: |
China
|
Brand Name: | Champion | Model Number: |
6fm60d
|
| Usage: |
UPS
|
Voltage: |
12v
|
Sealed Type: |
Sealed
|
| Maintenance Type: |
Free
|
Size: |
260*167*211mm
|
Weight: |
18kg
|
Applications:
· Electric Powered Vehicles
· Golf Cars and Buggies
· Wheel Chairs
· Power Tools
· Control System
· off grid power systome
· UPS systems
· PV applications
Specifications:
|
Nominal Voltage |
12V |
|
|
Nominal Capacity(10HR) |
60AH |
|
|
Dimension |
Length |
348±3mm (20.55 inches) |
|
Width |
167±2mm (9.45 inches) |
|
|
Container Height |
178±2mm (8.58 inches) |
|
|
Total Height (with Terminal) |
178±2mm (8.81 inches) |
|
|
Approx Weight |
Approx 18.0 Kg |
|
|
Terminal |
M6 |
|
|
Container Material |
ABS |
|
|
Rated Capacity |
10hr,1.80V/cell,25℃/77℉ |
60.0 AH |
|
5hr,1.75V/cell,25℃/77℉ |
55.0 A H |
|
|
3hr,1.75V/cell,25℃/77℉ |
45.7 AH |
|
|
1hr,1.60V/cell,25℃/77℉ |
34.7 AH |
|
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Terminal | Weight | |||
| (V) | (Ah) | L | W | H | TH | Type | Position | (Kg±5%) | |
| 6FM7D | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.15 |
| 6FM12D | 12 | 12.0 | 151 | 98 | 95 | 101 | F2/F1 | 1 | 3.45 |
| 6FM18D | 12 | 18.0 | 181 | 77 | 167 | 167 | F17/F18 | 3 | 5.25 |
| 6FM24D | 12 | 24.0 | 166 | 175 | 125 | 125 | F17/F18 | 3 | 7.4 |
| 3FM100D | 6 | 100 | 194 | 170 | 205 | 210 | F14 | 4 | 15.5 |
| 3FM150D | 6 | 150 | 260 | 180 | 245 | 250 | F13 | 5 | 23 |
| 3FM180D | 6 | 180 | 307 | 169 | 220 | 225 | F13 | 5 | 27 |
| 3FM200D | 6 | 200 | 321 | 176 | 226 | 229 | F13 | 4 | 29.5 |
| 3FM300D | 6 | 300 | 295 | 178 | 345 | 348 | F13 | 5 | 47 |
| 4FM180D | 8 | 180 | 260 | 182 | 295 | 298 | F13 | 6 | 36.5 |
| 6FM33D | 12 | 33 | 195 | 130 | 155 | 166 | F14 | 6 | 10 |
| 6FM40D | 12 | 40 | 197 | 165 | 170 | 170 | F14 | 3 | 12.5 |
| 6FM50D | 12 | 50 | 229 | 138 | 211 | 214 | F14 | 6 | 15.5 |
| 6FM50AD | 12 | 50 | 229 | 138 | 205 | 210 | F14 | 6 | 15.5 |
| 6FM70D | 12 | 70 | 260 | 168 | 211 | 214 | F14 | 6 | 21.5 |
| 6FM65D | 12 | 65 | 350 | 167 | 179 | 179 | F14 | 6 | 20 |
| 6FM90D | 12 | 90 | 306 | 169 | 211 | 214 | F14 | 6 | 27 |
| 6FM100D | 12 | 100 | 330 | 171 | 214 | 220 | F14 | 6 | 29.5 |
| 6FM120AD | 12 | 120 | 409 | 176 | 225 | 225 | F13 | 6 | 34 |
| 6FM120D | 12 | 120 | 406 | 173 | 208 | 238 | F13 | 6 | 34 |
| 6FM150D | 12 | 150 | 485 | 172 | 240 | 240 | F13 | 6 | 43 |
| 6FM160D | 12 | 160 | 530 | 207 | 210 | 213 | F13 | 2 | 47.5 |
| 6FM180D | 12 | 180 | 52.5 | ||||||
| 6FM200D | 12 | 200 | 522 | 238 | 218 | 221 | F13 | 2 | 59.5 |
| 6FM250D | 12 | 250 | 521 | 269 | 220 | 223 | F13 | 2 | 71 |
| GFM100D | 2 | 100 | 171 | 72 | 205 | 210 | F13 | 7 | 5.6 |
| GFM150D | 2 | 150 | 171 | 102 | 206 | 221 | F13 | 4 | 8 |
| GFM200D | 2 | 200 | 171 | 111 | 330 | 364 | F12 | 7 | 12.8 |
| GFM300D | 2 | 300 | 171 | 151 | 330 | 364 | F12 | 7 | 18 |
| GFM400D | 2 | 400 | 210 | 175 | 330 | 367 | F12 | 8 | 25 |
| GFM500D | 2 | 500 | 241 | 175 | 330 | 365 | F12 | 8 | 30 |
| GFM600D | 2 | 600 | 302 | 175 | 330 | 367 | F12 | 8 | 36 |
| GFM800D | 2 | 800 | 410 | 175 | 330 | 367 | F12 | 9 | 50 |
| GFM1000D | 2 | 1000 | 475 | 175 | 330 | 367 | F12 | 9 | 60 |
| GFM1500D | 2 | 1500 | 400 | 350 | 345 | 382 | F12 | 10 | 93 |
| GFM2000D | 2 | 2000 | 490 | 350 | 345 | 382 | F12 | 11 | 120 |
| GFM3000D | 2 | 3000 | 710 | 350 | 345 | 382 | F12 | 11 | 180 |
Competitive Advantage:
· 100% more cyclic life through innovation
· Wide operating temperature range from -20 °C to 60°C
· Low self-discharge rate ,less than 3% per month
· Good deep cycle performance: up to 750 cycles @80% DOD
· Excellent deep discharge recovery capability, 1.3 times quick than normal type
· IEC, UL, CE, ISO certificates qualified
· Short lead time : 25 days , beat 85% China factories
· Long warranty: 2 -3 years from the manufacturing date
