Solar Power Inverter AGM And Gel Batteries 28ah 12v Deep Cycle SLA Batteries
Solar Power Inverter Gel and AGM Battery 28ah 12v Deep Cycle Lead Acid Battery
Description:
Champion supply deep cycle SLA batteries for most of UPS systems. As larger systems (such as for data centers) require detailed calculation of the load, inverter efficiency, and battery characteristics to ensure the required endurance is without problem,so, the deep cycle type will be very suitable for long time power backup and great at cyclic life.
The run-time for a battery-operated UPS depends on the type and size of batteries and rate of discharge, and the efficiency of the inverter. The total capacity of a lead acid battery is a function of the rate at which it is discharged, this depend on professional engineer's calculation ,Champion has a group of tech team,who are average more than 10 years in this field,will provide you with the best solution.
Applications:
Offline or standby UPS
DC power UPS
Line-interactive UPS
off-grid power supply
Hybrid (double conversion on demand) UPS
solar system
Online UPS
wind power system
Diesel rotary UPS
Specifications:
| Model | Voltage | Capacity | Dimension(mm) | Terminal | Terminal | Weight | |||
| (V) | (Ah) | L | W | H | TH | Type | Position | (Kg±5%) | |
| 6FM7D | 12 | 7.0 | 151 | 65 | 94 | 100 | F1/F2 | 1 | 2.15 |
| 6FM12D | 12 | 12.0 | 151 | 98 | 95 | 101 | F2/F1 | 1 | 3.45 |
| 6FM18D | 12 | 18.0 | 181 | 77 | 167 | 167 | F17/F18 | 3 | 5.25 |
| 6FM24D | 12 | 24.0 | 166 | 175 | 125 | 125 | F17/F18 | 3 | 7.4 |
| 3FM100D | 6 | 100 | 194 | 170 | 205 | 210 | F14 | 4 | 15.5 |
| 3FM150D | 6 | 150 | 260 | 180 | 245 | 250 | F13 | 5 | 23 |
| 3FM180D | 6 | 180 | 307 | 169 | 220 | 225 | F13 | 5 | 27 |
| 3FM200D | 6 | 200 | 321 | 176 | 226 | 229 | F13 | 4 | 29.5 |
| 3FM300D | 6 | 300 | 295 | 178 | 345 | 348 | F13 | 5 | 47 |
| 4FM180D | 8 | 180 | 260 | 182 | 295 | 298 | F13 | 6 | 36.5 |
| 6FM33D | 12 | 33 | 195 | 130 | 155 | 166 | F14 | 6 | 10 |
| 6FM40D | 12 | 40 | 197 | 165 | 170 | 170 | F14 | 3 | 12.5 |
| 6FM50D | 12 | 50 | 229 | 138 | 211 | 214 | F14 | 6 | 15.5 |
| 6FM50AD | 12 | 50 | 229 | 138 | 205 | 210 | F14 | 6 | 15.5 |
| 6FM70D | 12 | 70 | 260 | 168 | 211 | 214 | F14 | 6 | 21.5 |
| 6FM65D | 12 | 65 | 350 | 167 | 179 | 179 | F14 | 6 | 20 |
| 6FM90D | 12 | 90 | 306 | 169 | 211 | 214 | F14 | 6 | 27 |
| 6FM100D | 12 | 100 | 330 | 171 | 214 | 220 | F14 | 6 | 29.5 |
| 6FM120AD | 12 | 120 | 409 | 176 | 225 | 225 | F13 | 6 | 34 |
| 6FM120D | 12 | 120 | 406 | 173 | 208 | 238 | F13 | 6 | 34 |
| 6FM150D | 12 | 150 | 485 | 172 | 240 | 240 | F13 | 6 | 43 |
| 6FM160D | 12 | 160 | 530 | 207 | 210 | 213 | F13 | 2 | 47.5 |
| 6FM180D | 12 | 180 | 52.5 | ||||||
| 6FM200D | 12 | 200 | 522 | 238 | 218 | 221 | F13 | 2 | 59.5 |
| 6FM250D | 12 | 250 | 521 | 269 | 220 | 223 | F13 | 2 | 71 |
| GFM100D | 2 | 100 | 171 | 72 | 205 | 210 | F13 | 7 | 5.6 |
| GFM150D | 2 | 150 | 171 | 102 | 206 | 221 | F13 | 4 | 8 |
| GFM200D | 2 | 200 | 171 | 111 | 330 | 364 | F12 | 7 | 12.8 |
| GFM300D | 2 | 300 | 171 | 151 | 330 | 364 | F12 | 7 | 18 |
| GFM400D | 2 | 400 | 210 | 175 | 330 | 367 | F12 | 8 | 25 |
| GFM500D | 2 | 500 | 241 | 175 | 330 | 365 | F12 | 8 | 30 |
| GFM600D | 2 | 600 | 302 | 175 | 330 | 367 | F12 | 8 | 36 |
| GFM800D | 2 | 800 | 410 | 175 | 330 | 367 | F12 | 9 | 50 |
| GFM1000D | 2 | 1000 | 475 | 175 | 330 | 367 | F12 | 9 | 60 |
| GFM1500D | 2 | 1500 | 400 | 350 | 345 | 382 | F12 | 10 | 93 |
| GFM2000D | 2 | 2000 | 490 | 350 | 345 | 382 | F12 | 11 | 120 |
| GFM3000D | 2 | 3000 | 710 | 350 | 345 | 382 | F12 | 11 | 180 |
Competitive Advantage:
Best cost performance
Deep cycle and better recover capacity
Capable of high discharge rates
Long cyclic service life
First class ABS container
Top lead of purity 99.994%
Manufacture with more than 22 years history
No 8th largest factory in China
