SMD1010 Indoor Advertising LED Display Video Wall Full Color For Important Meeting
SMD1010 Indoor Advertising LED Display Video Wall Full Color For Important Meeting
► Gapless installation, wider viewing angle, good color uniformity
► Soft images,green and environmental protection
► High refresh rate, remove ghost without trailing
► Locating slot work with dowel pin to ensure good flatness
►16bit gray scale processing, color expression more naturally
| Pixel pitch(mm) | 1.923 |
| Pixel Configuration | SMD1010 |
| Pixel density(dots/m2) | 270400 |
| Module resolution(W×H) | 104×156 |
| Module size (mm) | 200(W)×300(H) |
| Module weight (kg) | 0.4 |
| Maximum power consumption of the module(W) | 40 |
| Module of cabinet (W×H) | 2×1 |
| Cabinet resolution(W×H) | 208×156 |
| Cabinet size (mm) | 400(W)×300(H)×66(D) |
| Cabinet area(m2) | 0.12 |
| Cabinet weight (kg) | 4.6 |
| Cabinet level up degree(mm) | ≤0.2 |
| Maintenance mode | Front/Rear |
| Cabinet raw material | Die-casting aluminum |
| White Balance Brightness (nits) | ≥800(6500K) |
| Color Temperature (K) | 3200—9300 (adjustable) |
| Viewing Angle (Horizontal / Vertical) | 160/160 |
| Contrast | 4000:01:00 |
| Peak power consumption (W / m2) | 800 |
| Average power consumption (W / m2) | 250 |
| Power supply requirements | AC90~264V,frequency 47-63(Hz) |
| Frame rate (Hz) | 50&60 |
| Drive mode | Constant drive,1/26 |
| Grayscale level | 65536 |
| Refresh rate (Hz) | ≥3840 |
| Number of color processing bits | 16bit |
| Video playback capabilities | 2KHD,4KHD |
| Operating temperature / humidity range (℃ / RH) | -20 – 60 / 10%-85%RH |
| Applicable standards | CCC,TUV-CE,ETL |
Product Describtion:
Our Service and Mission:
Eachinled has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
