Automatic Punching PU Shutter Door Roll Forming Machine Flat Injection 24 * 0.6 * 0.9m
24*0.6*0.9m 8 - 15m/min Automatic Punching PU Shutter Door Roll Forming Machine Flat Injection
PU Shutter Door Technical Parameter
1. Steel Sheet Thickness: 0.27-0.4mm (depend on requirement )
2. Cutting: fly saw cutting
3. Transmission way: chain
4. Material of blad: Cr12, quenching treatment
5. Capacity of Decoiler: 3 ton hydraulic decoiler
6. Forming Speed: 8-15m/min
7. Roller Groups: 46 stations
8. Roller Material: GCr15 grade steel, quenching treatment
9. Material: color-coated galvanized steel
10. Principal Axis: 45# high grade steel with quenching treatment
11. Main Motor Power: 11 Kw
PU Shutter Door Main Components
| S.N |
Equipment name
|
Quantity |
| 1. |
3T manual un-coiler
|
1 set |
| 2. |
Guide and leveling device
|
1 set |
| 3. |
Main roll forming machine
|
1 set |
| 4. |
Foaming machine(just foamed one owned)
|
1 set |
| 5. |
Straighten device
|
1 set |
| 6. |
Control system (including control box)
|
1 set |
| 7. |
Out tables
|
2 sets |
| 8. |
Fly saw cutting
|
1 set |
| 9. |
Spare parts and tools
|
1 set |
Advantage for PU Shutter Door
1. Reasonable Price
2. High Quality
3. 12 Months Warranty
4. More Than 10 Years Experience
5. Durable
6. Reliable
Working Flow of PU Shutter Door
Decoiler--feedingdevice--mainforming--PU injection--straightendevice--punching--FlysawCutting ---run out table
Profiles of PU Shutter Door
