CCA 75ohm Low Loss Coaxial Cable 0.30"/7.25mm Solid PE Coaxial Cable Copper Clad Aluminum(90%)
Price:
Negotiable
MOQ:
30 KM
Delivery Time:
Normally 15 working days
Brand:
Zion communication OR OEM
Product Description
|
75 Ohm CATV coaxial Cable NO.7100433 |
|||
| Construction Parameters: | |||
| Inner Conductor | 7×0.016"/7×0.4mm/7×26 AWG Cu | ||
| Dielectric | 0.30"/7.25mm Solid PE | ||
| Shield | Copper Clad Aluminum(90%) | ||
| Jacket | 10.2±0.10mm PVC | ||
| Application | For Use in Longer CATV Run Lengths | ||
| Electrical Characteristics: | |||
| Inner Conductor Resistance | 22.2Ω/KM at 20℃ | ||
| Capacitance | 67 ±3 pF/m | ||
| Impedance | 75 ± 3 Ω | ||
| Return loss | between 5 and 1000MHz: > 22dB | ||
| Velocity of Propagation | 0.85 | ||
| Sparker Test (VAC) | 4 | ||
| Mechanical and Envrionmental Properties | |||
| Cable bend radius | 10 times the cable diameter | ||
| Operating Temp Range | -20 ℃ to 70℃ | ||
| Cable diamensions | 6.6±0.15mm PVC | ||
| Cross Section | |||
 |
|||
| Attenuation(20℃): | |||
| Frequency (MHZ) | Max Attenuation(dB/100ft) | Max Attenuation (dB/100m) | |
| 10 | 2.90 | ||
| 50 | 4.50 | ||
| 100 | 6.60 | ||
| 200 | 10.90 | ||
| 400 | 13.80 | ||
| 850 | 23.60 | ||
| 950 | 26.80 | ||
| 1000 | 27.50 | ||
| Order Informations: | |||
| Marking |
HELLOSIGNAL KX 8 Cu 90% CCA PVC CATV COAXIAL CABLE 7100433 ×××M/FT |
||
| Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
| Delivery time | Normally 25 days after received the deposit. | ||
| Brand | HELLOSIGNAL® OR OEM | ||
KX 8 Cu 90% CCA PVCSimilar Products
