RG59 BC 95% BC PVC CM 75ohm CCTV Coaxial Cable For Communication

Price Negotiable

Price: Negotiable

MOQ: 30 KM

Delivery Time: 25 working days

Brand: Zion communication OR OEM

Product Description

RG59 BC 95% BC PVC CM 75 Ohm CCTV coaxial Cable NO.7100161



Construction Parameters:
Inner Conductor	0.032"/0.81mm/20 AWG BC
Dielectric	0.144"/3.66mm Foamed PE
Shield 1	/
Shield 2	0.12mm Bare Copper braid wire 95% coverage
Jacket	0.238"±0.006"/6.05±0.15mm PVC CM
Jacket Thickness	0.032"/0.81mm
Application	For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance	The Max. at 20℃ shall be < 33.4 Ω/km 10.2Ω/1000ft

Capacitance	52 ±3 pF/m 15.8 ±1 pF/ft
Impedance	75 ± 3 Ω
Return loss	between 5 and 1000MHz: > 22dB
Velocity of Propagation	0.85
Sparker Test (VAC)	4

Mechanical and Envrionmental Properties
Cable bend radius	10 times the cable diameter
Operating Temp Range	-20 ℃ to 60℃
Cable diamensions	0.238"±0.006"/6.05±0.15mm PVC CM

Cross Section














Attenuation(20℃):
Frequency (MHZ)	Max Attenuation(dB/100ft)	Max Attenuation (dB/100m)
5	0.86	2.82
55	2.05	6.73
83	2.45	8.04
187	3.60	11.81
211	3.80	12.47
250	4.10	13.45
300	4.45	14.60
350	4.80	15.75
400	5.10	16.73
450	5.40	17.72
500	5.70	18.70
550	5.95	19.52
600	6.20	20.34
750	6.97	22.87
865	7.52	24.67
1000	8.12	26.64

Order Informations:
Marking	HELLOSIGNAL RG59 BC 95% BC PVC CCTV COAXIAL CABLE 7100161 ×××M/FT
Package	Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time	Normally 25 days after received the deposit.
Brand	HELLOSIGNAL®OR OEM
