quality rg11 Tri-Shield PVC jacket 75 Ohm CATV coaxial Cable with messenger wire

Price Negotiable

Price: Negotiable

MOQ: 30 KM

Delivery Time: Normally 15 working days

Brand: Zion communication OR OEM

Product Description

RG11 Tri 60% PVC Messenger 75 Ohm CATV coaxial Cable NO.7100226



Construction Parameters:
Inner Conductor	0.064"/1.63mm/14AWG CCS
Dielectric	0.280"/7.11mm Foamed PE
Shield 1	0.287"/7.29mm Bonded Aluminum PET
Shield 2	Aluminum braid wire 60% coverage
Shield 3	Aluminum Laminated Tape(Non-bonded)
Jacket	0.400"±0.006"/10.16±0.15mm PVC
Jacket Thickness	0.039"/0.99mm
Messenger	0.072"/1.83mm
Minimum Breaking Strength	365lbs./166kg
Application	For Use in Longer CATV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance	The Max. at 20℃ shall be < 38 Ω/km < 11.59 Ω/1000ft

Capacitance	52 ±3 pF/m 15.85 ±1 pF/ft
Impedance	75 ± 3 Ω
Return loss	between 5 and 1000MHz: > 22dB
Velocity of Propagation	0.85
Sparker Test (VAC)	4

Mechanical and Envrionmental Properties
Cable bend radius	10 times the cable diameter
Operating Temp Range	-20 ℃ to 60℃
Cable diamensions	0.40''±0.006''/10.21±0.15 mm PVC

Cross Section














Attenuation(20℃):
Frequency (MHZ)	Max Attenuation(dB/100ft)	Max Attenuation (dB/100m)
5	0.38	1.25
55	0.96	3.15
83	1.18	3.87
187	1.75	5.74
211	1.90	6.23
250	2.05	6.72
300	2.25	7.38
350	2.42	7.94
400	2.60	8.53
450	2.75	9.02
500	2.90	9.51
550	3.04	9.97
600	3.18	10.43
750	3.65	11.97
865	3.98	13.05
1000	4.35	14.27

Order Informations:
Marking	HELLOSIGNAL RG11 S 60%PVC Messenger CATV COAXIAL CABLE 7100226 ×××M/FT
Package	Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time	Normally 25 days after received the deposit.
Brand	HELLOSIGNAL^® OR OEM
