S/FTP CAT 6A LSZH Ethernet Cable with 750 MHz Bandwidth, High-Power PoE Support, and Double-Shielded Construction

Price Negotiable
Price: Negotiable
MOQ: 100m, 305m,500m
Delivery Time: Normally 25 working days
Brand: hellosignal
Product Description

 High-Performance S/FTP CAT 6A LSZH Cable (No. 7112346E)

This S/FTP Category 6A cable is engineered for demanding high-speed network environments, providing superior data integrity and robust safety features. Optimized for 10 Gigabit Ethernet, its advanced double-shielded construction (Screened with Foiled Twisted Pairs) ensures maximum protection against electromagnetic interference (EMI) and crosstalk.

Common Applications Ethernet Cable



 Key Product Highlights

•  Exceptional Bandwidth: Exceeds the Cat 6A standard (500 MHz) with a Max Frequency of 750 MHz, offering significant performance headroom for stable 10GBASE-T operation.
•  Ultimate Shielding (S/FTP): Features individual foil shields on all four pairs, plus a comprehensive outer shield comprising aluminum foil and high-coverage braiding, ideal for noisy electrical environments.
•  High-Power PoE Support: Fully compliant with PoE Type 4, enabling high-wattage power delivery (up to 90W/100W) to devices such as PTZ cameras, WAPs, and digital displays.
•  Safety Compliant: Equipped with an LSZH (Low Smoke Zero Halogen) jacket, making it mandatory for public buildings, data centers, and enclosed spaces where fire safety is critical.




 Technical Specification: Construction Details

Feature

Specification

Notes

Cable Type

S/FTP Cat 6A

Screened/Foiled Twisted Pair

Conductor

0.58 ± 0.005 mm Solid CCA

Approximately 23 AWG

Insulation

1.40 ± 0.05 mm Foam PE

High-quality dielectric

Pair Shielding

AL/PET Foil (100% Coverage)

Eliminates Pair-to-Pair Crosstalk

Overall Shield

65U Aluminum Foil + Braiding

Braiding: 5×16×0.12mm Al-Mg, 40% Coverage

Drain Wire

0.5 mm TCCA

Tinned Copper Clad Aluminum

Outer Jacket

7.5 ± 0.2 mm LSZH

Low Smoke Zero Halogen

Jacket Color

Customization is available



SFTP CAT 6A LSZH Ethernet Cable Cross Section




 Electrical Performance Characteristics

This cable is guaranteed to maintain low signal loss and excellent impedance control across high frequencies.

Parameter

Value

Condition

Max Frequency

750 MHz

Superior to 500 MHz standard

DC Resistance

< 10.79 Ω / 100m

at 20°C

Characteristic Impedance

100 ± 15 Ω

1 – 100 MHz

100 ± 25 Ω

100 – 750 MHz

NVP (Nominal Velocity)

0.74

High speed of signal propagation

Delay Skew

≤ 25 ns / 100m

Ensures data synchronization

Mutual Capacitance

5.6 nF / 100m

 Why Choose Zion Communication as Your Supplier


 Compliance & Application Support

Category

Details

Reference Standards

ISO/IEC 11801-1, ANSI/TIA-568.2-D, UL444, IEC60332-1

Primary Application

10GBASE-T Ethernet (10 Gigabit)

Supported Applications

1000BASE-T, 100BASE-T, VoIP, ISDN, Analog and Data video

PoE Support

POE Type 1, 2, 3, 4




  Physical and Environmental Properties

Property

Value

Operating Temperature

−20 to 60 °C

Pulling Tension (Max)

≥ 13.5 MPa

Bend Radius (Min)

8 × OD of Jacket
