РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
Price:
HANGZHOU ZION COMMUNICATION CO.,LTD
MOQ:
30 KM
Delivery Time:
Normally 25 working days
Brand:
hellosignal
Product Description
https://www.zion-communication.com/cctv-coaxial-cable-products-catalog.html
|
РК75-3-32 75 Ohm CCTV coaxial Cable NO.7100365 |
|||
| Construction Parameters: | |||
| Inner Conductor | 0.024"/0.60mm/22 AWG CU | ||
| Dielectric | 0.144"/2.70mm FPE | ||
| Shield | 96/ 0.12mm CCAM | ||
| Jacket | 4.4mmPVC | ||
| Jacket Thickness | 0.032"/0.81mm | ||
| Application | For Use in Longer CCTV Run Lengths | ||
| Electrical Characteristics: | |||
| Inner Conductor Resistance | The Max. at 20℃ shall be < 63Ω/km | ||
| Capacitance | 56.5±1 pF/m | ||
| Impedance | 75±5 Ω | ||
| Return loss | between 5 and 1000MHz: > 20dB | ||
| Velocity of Propagation | 0.82 | ||
| Sparker Test (VAC) | |||
| Mechanical and Envrionmental Properties | |||
| Cable bend radius | 10 times the cable diameter | ||
| Operating Temp Range | -20 ℃ to 60℃ | ||
| Cable diamensions | 0.130"±0.006"/3.30±0.30mm PVC | ||
| Cross Section | |||
 |
|||
| Attenuation(20℃): | |||
| Frequency (MHZ) | Max Attenuation(dB/100m) | ||
| 10 | 3.54 | ||
| 50 | 8.04 | ||
| 200 | 16.50 | ||
| 470 | 25.80 | ||
| 862 | 35.80 | ||
| 1000 | 39.00 | ||
| 1350 | 46.10 | ||
| 1750 | 53.50 | ||
| 2150 | 60.00 | ||
| 2400 | 64.50 | ||
| Order Informations: | |||
| Marking |
HELLOSIGNAL РК75-3-32 CCTV COAXIAL CABLE 7100365 ×××M/FT |
||
| Package | Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet … | ||
| Delivery time | Normally 25 days after received the deposit. | ||
| Brand | HELLOSIGNAL® OR OEM | ||
