IND 10 ISUZU 3 Ton Road Wrecker Truck 4X2 Truck with 45° Angle
IND 10 ISUZU 3 Ton Boom Capacity 4X2 Light Duty Wrecker Tow Truck
Description:
1) Flat bed tow truck can tow 2 units truck at one time. It ’ s mainly for towing light cargo truck, mini bus and car;
2) Wrecker truck is mainly for towing medium duty and heavy duty cargo truck and bus;
3) Rotator tow truck, its boom can rotate 360 degree and suitable for all the direction towing work. It ’ s mainly for towing heavy duty cargo truck and super heavy duty trailer.
Applications:
Our high quality and competitive price 3 ton SYDW3IS rotator wrecker with wireless remote control is mainly for towing heavy duty cargo truck and super heavy duty trailer.
Competitive Advantage:
1) Wireless remote control boom, winch and under - lift is optional;
2) 6 ton towing rating;
3) Mainly made by alloy steel, high quality and competitive price.
Specifications:
IND 10 ISUZU 3 Ton Boom Capacity 4X2 Light Duty Wrecker Tow Truck
|
A. Boom |
|
|
Model |
SY3D |
|
Rating of the boom ( lb / kg ) Retracted at 19 ° Extended at 19 ° |
6600 / 3000 4400 / 2000 |
|
Max . Angle ( ° ) |
45 |
|
Hook height ( inch / mm ) |
149 ” / 3800 |
|
The length to the tail of truck fully extended and min . angle ( inch / mm ) |
68 ” / 1725 |
|
B. Underlift |
|
|
Model |
SY3T |
|
Towing rating ( lb / kg ) |
13200 / 6000 |
|
Capacity fully extended ( lb / kg ) |
4000 / 1820 |
|
Capacity fully retracted ( lb / kg ) |
5500 / 2500 |
|
The length to the tail of the truck fully retracted ( inch / mm ) |
45 ” / 1160 |
|
The length to the tail of the truck fully extended ( inch / mm ) |
69 ” / 1750 |
|
Underlift tilt ( ° ) |
+ 11, - 3 |
|
C. Winch |
|
|
Model |
SY001 |
|
Capacity of winch ( lb / kg ) |
6600 / 3000 |
|
Type of winch |
Worm gear |
|
Diameter and length of steel cable |
4 / 9 ” x 50 ’ / 11 x 15000 |
|
D. Chassis Recommendations |
|
|
GVW ( lb / kg ) |
13200 / 6000 – 16500 / 7500 |
|
C.A ( inch / mm ) |
92 ” / 2350 – 131 ” / 3320 |
|
STANDARD FEATURES |
|
|
|
|
Notice: Equipment can be modified according to the customer ’ s requirement. |
|
