Water Cooling Engine Cummins Diesel Generator 50Hz Powered 90KW 115KVA
Cummins Engine Silent Diesel Generator Set 50Hz Powered 90KW 115KVA
Technical date:
Output Ratings:
|
Gensets Model |
Prime |
Standby |
||
|
kW |
kVA |
kW |
kVA |
|
|
LF125CS |
90 |
115 |
100 |
125 |
|
Voltage |
380V-415V |
220V-240V |
190V-208V |
|
Amps |
157-171 |
271-295 |
312-342 |
Ratings and Performance Data:
|
Engine Brand |
Cummins |
|
|
Engine Model |
6BTA5.9G2 |
|
|
Alternator Brand |
Stamford |
|
|
Alternator Model |
UCI274D |
|
|
Control System |
DSE6020 / DSE7320 |
|
|
Standard Noise Level@7m (Soundproof Sets) |
72 db |
|
|
Circuit Breaker Type |
3 Pole MCCB |
|
|
Frequency & Phase |
50Hz & 3PH |
|
|
Engine Speed: RPM |
1500 |
|
|
Fuel Tank Capacity: L |
Open |
270 |
|
Soundproof |
||
|
Fuel Consumption (l/hr) |
110% Load |
30 |
|
100% Load |
27 |
|
|
75% Load |
20 |
|
|
50% Load |
14 |
|
|
Lubricant |
15W40-CF4 Upgrade |
|
|
Total Lubricant Capacity (L) |
16 |
|
Features
- Standard open type is good to working in engine room with ventilation system.
- The super silent model (up to 50kw) has electronic cooling fan and special design low noise level canopy. which is specialized for low noise level environment, such as office building, villa, museum.
- Standard soundproof type(IP21) will be working perfectly in the open air
- All standard type can be working in 3rd explosive area for mining industry, special design will be suitable for 2nd explosive area.
- All functional components are modular design, for fast repair, replace, and reduce stock, which can satisfy rental business.
- 50℃ radiator
- IP54 (soundproof sets), IP56 (control system)
- Base fuel tank for at least 8 hours running
- For friendly experience, all I/O control interface and daily maintenance parts are combined in one side.
