Protable Generator  Specification LR1500 Heavy Duty Design

Rated frequency (Hz):

50

Rated voltage (V):

220V/230V/240V

Rated output power (kW):

1

Max output power (kW):

1.1

Rated rotation speed (rpm):

3000

DC output:

12V 8A

Power factor cos:

1

Phase number :

Single phase

Noise level dB (A)/4m (zero load-full load):

96

Fule tank[L]:

5

Overall dimensions [mm] ( L x W x H ):

470x365x405

N.W/G.W[Kg]:

27/28

Engine model:

HR90

Engine type:

4-stroke

Displacement [cc]:

87

Compression ratio:

8.5:1

Rated power [(HP/rpm]:

2.6/3600

Rated rotation speed (rpm):

3600

T.C.I:

 with

Spark plug:

E7TC

Starting system:

Recoil starter

Rotation direction (view from flywheel):

Clockwise

Fuel type:

Automotive Unleaded Gasoline

Lube oil brand:

SAE10W30 (above CC grade)

Low oil alarm system :

Yes
