Direct injection Industrial Diesel Engines , Air Cooled Diesel Engines 4 Hp Crankshaft / Camshaft
Direct injection Industrial Diesel Engines Air cooled Single Cylinder 4 Hp Crankshaft / Camshaft
Product Features:
- CE certificate
- Single-cylinder,4-stroke ari-cooled
- Bore stroke(mm):70 * 55
- Stable voltage and frequency
- Start easily
Specifications:
|
LR170 |
4hp diesel engine specification |
|
Engine type: |
4-stroke single cylinder, air-cooled diesel engine |
|
Combustion system: |
Direct injection |
|
Bore × stroke: |
70mm×55mm |
|
Displacement: |
211cc |
|
Engine speed(rpm): |
3000 /3600 |
|
Max. output(hp): |
3.8 /4.2 |
|
Continuous output(hp): |
3.4 /3.8 |
|
|
Crankshaft or camshaft(camshaft PTO rpm is 1/2) |
|
Starting system: |
Recoil or electric(optional) |
|
Fuel tank capacity: |
2.5L |
|
Lube oil capacity(L): |
0.75L |
|
Net weight(recoil)(kg) |
27kg/28kg |
|
Net weight(electric)(kg) |
32kg/33kg |
|
Dimension(L×W×H)(mm): |
425×395×455 |
Production Machinery:
|
Machine Name |
Brand & Model No. |
Quantity |
Number of Year(s) Used |
|---|---|---|---|
|
Punching Machine |
J23, JB04-1 |
7 |
5.0 |
|
Cutting Machine |
215 |
3 |
5.0 |
|
Tube Bending Machine |
DB38 |
3 |
5.0 |
|
Plate Shearing Machine |
QC12Y-4*2500 |
1 |
5.0 |
|
Drilling Machine |
Z512,Z4116 |
8 |
5.0 |
|
Bench Milling Machine |
Xj51 |
1 |
5.0 |
|
Welding Machine |
TCW-32D,NBC-350, DN160 |
10 |
4.0 |
|
Winding Machine |
PR-2 |
2 |
4.0 |
|
Cleaning Machine |
ZQX-2000 |
1 |
3.0 |
|
Marking Machine |
HUAPU |
2 |
4.0 |
|
Hydraulic Machine |
MAOYI, 5T |
8 |
4.0 |
Testing Machinery:
|
Machine Name |
Brand & Model No. |
Quantity |
Number of Year(s) Used |
|---|---|---|---|
|
Withstand Voltage Tester |
CS2670A |
4 |
3.0 |
|
Low DC Resistance Tester |
TH2512, WB2511A |
2 |
3.0 |
|
Performance Test Bench |
No Information |
4 |
5.0 |
|
Spring Tension Tester |
TLS-S |
1 |
3.0 |
|
Rockwell Apparatus |
HR-150A |
2 |
3.0 |
|
Gear Runout Tester |
1-6mm |
1 |
3.0 |
|
Torque Tester |
NJ-100 |
1 |
3.0 |
|
Test Platform |
No Information |
1 |
3.0 |
|
Inverter Welder Tester |
SJ |
1 |
4.0 |
|
Turbine Dynamometer |
No Information |
2 |
4.0 |
Picrtures:
