AC Three Phase Perkins Open Diesel Generator Set Low Oil Pressure Electric Starter
Perkins Open Diesel Generator Set / Open Type Low Oil Pressure Electric Starter
Specifications:
1. Silent or open type is optional
2. Shutdown for overheating
3. low oil pressure
4. low coolant
Perkins open frame generator set:
|
ALTERNATOR |
Alternator Model |
HR28E |
|
Rated power (kw / kva) |
80/100 |
|
|
Voltage (V) |
400/230 |
|
|
Current (A) |
144 |
|
|
Frequency (Hz) |
50/60 |
|
|
Power factor cosφ |
0.8(lagging) |
|
|
Excitation mode |
Brushless self-excitation |
|
|
Phase/Connection |
3-phase 4-wire Y type connection |
|
|
Voltage regulation rated |
≤±1% |
|
|
Voltage Regulation |
Automatic |
|
|
Insulation grade |
H |
|
|
ENGINE |
Engine model |
6BTA5.9-G2 |
|
In taking method |
Turbocharged |
|
|
Bore x stroke (mm) |
114×135 |
|
|
Displacement (L) |
5.9 |
|
|
Compression ratio |
17.5:1 |
|
|
Rated power (kW) |
110 |
|
|
Lube oil capacity (L) |
12.1 |
|
|
Fuel consumption rate (g/kW.h) |
≤210 |
|
|
Starting system |
24V Electric starter |
|
|
Dimensions(L×W×H)mm |
2380×920×1350 |
|
|
Net Weight (Kg) |
1550 |
|
Functions:
- Automatic Start/Stop
- 3 start attempts failure and Automatic Crank Disconnect
- Parameters display(V/A/Hz/Hour)
- Engine monitoring and protection
- Change alternator exciting and Charge alternator fail alarm
- Running hour counting
- Settings can be adjustable via key buttons on front panel
Warranty:
1000hours / 1year
- During the guarantee period, we will supply freely the easy damaged parts for the possible problems except for the
incorrect operation.
- After expiration, we supply cost spare parts for alternator maintenance
