Ship / Automobile / Industrial Container Genset with Big Fuel Tank Worldwide Power Standard
Super Silent Container Genset with Big Fuel Tank Worldwide Power Standard for Ship / Automobile / Industrial
Specifications:
|
TECHANICAL DATA |
|||||
|
Generator set |
Type |
Open |
Open with ATS |
Silent |
Silent with ATS |
|
|
Genset Model |
LF30360 |
LF30360A |
LF30360S |
LF30360SA |
|
Prime Power Rating |
45KVA/36KW |
||||
|
Standby Power Rating |
50KVA/40KW |
||||
|
Size(mm) |
1700*850*1080 |
2300*1100*1250 |
|||
|
Weight(KG) |
865 |
1340 |
|||
|
|
Internal protection |
IP22 |
|||
|
|
Rate current(A) |
63 |
|||
|
|
Specific Fuel Consumption(L/H) @100% Load |
6.2 |
|||
|
|
|||||
|
|
Noise at 7 meters away(dB) |
N/A |
75db |
||
|
Engine |
Model |
4BT3.9G2 |
|||
|
NO. of Cylinder |
4 |
||||
|
Cylinder Type |
L |
||||
|
RPM |
1500 |
||||
|
Bore (mm) |
102 |
||||
|
Stroke(mm) |
120 |
||||
|
Speed Governor |
electronic |
||||
|
Start system(VDC) |
24 |
||||
|
Lub Oil Specification |
15W40 |
||||
|
Displacement(Ltrs) |
3.9 |
||||
|
Lub Oil Sump Capacity(Ltrs) |
7.5 |
||||
|
Coolant Capacity(Ltrs) |
7.9 |
||||
|
Air inspiration |
turbo |
||||
|
Phase |
3 |
||||
|
Alternator |
Brand |
STAMFORD |
EVO |
||
|
Model |
UCI224C |
TCU228A |
|||
|
3 Phase Voltage(1 Phase) Volts |
380-415(220-240) |
||||
|
RPM/Frequency |
1500rpm/50hz |
||||
|
Power Factor(%) |
0.8(lagging) |
||||
|
Voltage Tolerance(+/- %) |
1 |
||||
|
Insulation Class |
H |
||||
|
Control Panel |
Brand |
KUSING |
|||
|
Model |
AD6122 |
||||
|
Fuel Tank |
Capacity(Ltrs) |
143 |
|||
Quality Guarantee &Training
Quality Guarantee:
We guarantee that all the products and parts are original package and come from original brand
manufacturer
With the identity of OEM and support form original manufactory, we ensure stable and reliable
quality of our products.
Ensure stable and reliable quality of our products:
We will be responsible for repairing or replacing with new parts for all the malfunction caused by
gensets manufacturing objection (within one year or 1000 hours running after delivery),but it does
not include wearing parts, general gadget and any great damage caused by unsuitable operation
& maintenance even still under guaranty.
Training:
To help users to master the operation, maual and maintenance of Gensets, we specially provide
primary/secondary courses for them in the local or factory. we will also carry on upgrsde training
course termly.At the same time,the customer is allowable to access to join the training course in
Asia base that is held by the original engine manufacturer.
We are focused on making land type diesel generator set and exported to worldwde several years.
The engine brand: Cummins, Yangdong, YTO. The alterator euipped with Stamford or EVO.
We make sure all of parts are original from brand owner directly to meet our poducts high quality.
Why choose us
1. Depends on our professional engineering Team, We have the ability of development the
high-performance products.
2. Not only the high-performance products, our price are very fair in the market.
3. We have many experiences in cooperating with many famous and professional clients in the world.
4. We have wonderful pre-sale and after-sale service, to help visitors/clients to get what they need.
