4 Stroke Electric Start 5kw Diesel Power Generators With AVR , Low Oil Alarm System Air Cooled
4 Stroke Electric Start 5kw Diesel Power Generators With AVR , Low Oil Alarm System Air Cooled
Our Services:
1 - Guarantee for one year or 1000hours (according to whichever reaches first) from ex-factory date.
2 - During the guarantee period,our company will provide the free easy-damaged spare-parts for problems caused by our quality of production or raw material.
3 - After expiration,our company provides cost spare-parts maintenance for engines.
Specification:
Model No. | 6000SE |
Certificate | CE/GS |
Item Description | 4500W Diesel Generator |
(TECHNICAL SPECIFICATION) |
|
Generator | Type:Single-Phase |
| Power Factor: 1.0 |
| Voltage Regulate:AVR |
| Frequency Hz:50 |
| Voltage:230V |
| Voltage Regulation:± 1% @ full load or better |
| Frequency Variation : ± 1% @ full load or better |
| Rated AC Output (KVA):4.5 |
| Max AC Output (KVA): 5.0 |
Engine | Engine Model: JD186FA |
| Engine Type:4-stroke, single cylinder with Air-cooled |
| Bore x Stroke (mm):86×72 |
| Displacement (ml):418 |
| Max. output (HP/rpm):10.0/3600 |
| Fuel Tank Capacity (L):16 |
| Oil Capacity (L):1.65 |
| Fuel Consumption:285.7g/kw.h |
| Starting System:Recoil and Electric start |
Reliability Features | Operating Temperature:30-40 °C |
| Low oil shutdowns |
| Hour Meter |
| External emergency stop switch |
Panel | AC Circuit Breaker |
| 2X230V Sockets |
| DC Output: 12V/8.3A |
| 1 Set tools bag, 1 user manual |
Outside packing dimension(mm) | 915X540X470 |
Outside packing Net/Gross Weight(kgs): | 160 |
pcs/20'FCL: | 72 |
pcs/40'FCL: | 144 |
pcs/40'HQ: | 144 |
MOQ: | 72 |
Gasoline Generators Picture:
Manufacture's Advantages:
1. Our factory was founded in 1981.
2. Main Products: diesel generator sets, generators, engines, water pumps and other agricultural machinery products.
3. We have obtained the relevant certifications such as ISO, CE,ROHS, GS, TUV etc.
Guarantee Service
1. professional value-added technical support
2. warm before-sales & after-sales service
3. warranty period of 24 months or 1200 operating hours for diesel generators.
3. warranty period of 12 months or 1000 operating hours for gasoline generators.
