50Hz Air Cooled Single Cylinder Industrial Diesel Engines Direct Injection Vertical
4 Stroke Air Cooled Single Cylinder Direct Injection Vertical Diesel Engine
Diesel Engine Description
Prime Output: 1103kW @1500rpm
Standby Output: 1229kW @1500rpm
Displacement: 53.1L
Speed: 1500rpm or 1800rpm
Governor: Electrics
Cooling System: Fan with Radiator
Flywheel: SAE-00
Four Stroke:yes
Bore*Stroke: 170*195
Diesel Engine Technical Data:
| Standard engine … … … . | V-12 engine |
| Flywheel … … … … … … ... | Flywheel for 21" connection Teeth of flywheel: 218 J = 5.1 kgm² |
| Adaptor housing… … … ... | SAE 00 housing |
| Governor … … … … … … ... | Electronic governor |
| Cooling system… … … … | Air-to-water intercooler Fan blade Separate mounted radiator (optional) Heat exchanger is optional |
| Exhaust system… … … ... | 2 Turbocharger with counter flange Without exhaust silencer |
| Filter … … … … … … … … . | 2 air cleaner with restriction indicator Fuel twin cartridge filter 5 lube oil filter and 2 bypass oil filter |
| Electrics system… … … ... | Electric starter motor 9kW, 24VDC Starting relay, 24V Charging alternator 55A, 28VDC Oil pressure sensor with switch Coolant temperature sensor with switch Speed sensor for governor Lube oil pre-supply pump |
| Miscellaneous … … … … . | Green painting as standard 1 operation manual Without tool box |
Diesel Engine Features:
Manufacture's Advantages:
1. Our factory was founded in 1981.
2. Main Products: diesel generator sets, generators, engines, water pumps and other agricultural machinery products.
3. We have obtained the relevant certifications such as ISO, CE,ROHS, GS, TUV etc.
Guarantee Service
1. professional value-added technical support
2. warm before-sales & after-sales service
3. warranty period of 24 months or 1200 operating hours for diesel generators.
3. warranty period of 12 months or 1000 operating hours for gasoline generators.
