Air Cooled 2kVA Silent Diesel Generator Single Phase Recoil or Electric Start
Best Quality Air Cooled 2kVA Silent Diesel Generator Single Phase Recoil or Electric Start
Product Range:
1.Gasoline generator including 1kw,2kw,2.5kw,2.8kw,5kw,6kw,7kw,10kw.
Diesel generator including 3kw,5kw.
2. Optional Alternator: 100% Copper/ 100%Aluminium Wire
3.Recoil start and electric start
4.Single phase and three phase is available.
Product Features:
1.Small and portable
2.Stable running
3.Compact structure
4.Low fuel consumption
5.Easy and fast starting and installing
6.Low noise and small vibration
7.Rugged and reliable
8.Lightweight and good quality
Generator Parameter:
| Model | LR2500E |
| Rated frequency (Hz) | 50 / 60 |
| Rated output(kVA) | 2.0 / 2.2 |
| Max. ouput (kVA) | 2.3 / 2.5 |
| Rated voltage (V) | 115-230 / 120-240 |
| Rated current (A) | 17.4/8.7; 18.3/9.2 |
| Rated speed (r/min ) | 3000 / 3600 |
| Phase NO. | Single phase |
| Power factor (cosφ) | 1 |
| Insulation grade | F |
| Pole number | 2 |
| panel type | General panel |
| Volage (V) | 115-230 / 120-240 |
| Receptacle | Two receptacles |
| DC12V output | Connection pole output |
| Dimension:L×W×H(mm) | 670X490X550 |
| Dry weight (Kg) | 57 |
| Noise Level(7M) db(A) | 79 |
| Structure type | Open frame |
| Engine Model | 170F |
| Engine type | Single-cyinder,four-stroke,air-cooled |
| Cylinder NO.,-bore×stroke(mm) | 1-70X57 |
| Displacement(cc) | 219 |
| Rated power[kW(Hp)/(r/min)] | 2.5/3000; 2.8/3600 |
| Compression ratio | 20:1 |
| Rated rotation speed | 3000 / 3600 |
| Cooling system | Air cooled |
| Lubrication system | pressure splashed |
| Starting system | Recoil or Electric |
| Fuel type | 0#(summer)-10#(winter)-20#(chillness) diesel |
| Fuel tank capacity (L) | 12 |
| Continuous running time (hr) | 15.5 |
| Place of origin | Guangzhou,China |
| Starting Type | Recoil / Electric |
Specifications
Reliable quality for long life;
100% copper wire;
Low fuel consumption;
One year warranty;
CE, ISO Certifications.
FAQ
Q1: What's your MOQ of this Item?
A1: 1 PCS
Q2:What's your payment term?
A2:L/C and T/T
Q3:Where is your Loading Port?
A3:Guangzhou,China Port or according to your requirements.
Q4:How about your quality control in your factory?
A4:Our company are always paying great attentions to the quality controlling from the beginning to the end.
Q5: Can you produce according to the samples?
A5: Yes, we can produce by your samples or technical drawings.
Q6: How do you make our business long-term and good relationship?
A6:1. We keep good quality and competitive price to ensure our customers' benefit;
We respect every customer as our friend and we sincerely do business and make friends
with them, no matter where they come from.
Our Services
1.OEM is available,we accept your brand and designing of packing cartons.
2.We supply samples for your reference and checking.
3.Delivery time:at least 15 days after receiving your deposit.
4.Warranty:1 Year,except the easily damaged parts.
