Manual / Electric Start Single Cylinder Industrial Diesel Engines with Low Noise Compact Lightweight
Manual / Electric Start Single Cylinder 4.5HP Diesel Engine with Low Noise , Compact and Lightweight
Product Strength:
Easy Start
Very Low Noise
Compact and lightweight
Low Fuel Consumption
Supply Power for pumps generators construction machinery
Application:
A simple, compact, and lightweight engine for a wide array of applications.Great for agricultural, rental, construction site, and home use.
Specifications:
| Model | LE170F(E) |
| Type | Single cylinder, vertical, 4-stroke, air cooled |
| Bore*stroke (mm) | 70*55 |
| Dislacement (L) | 0.211 |
| Combustion system | direct injection |
| Rated output KW (HP) / rpm | 2.5 (3.4) / 3000 2.98(4.0) / 3600 |
| Max output KW (HP) / rpm | 2.8 (3.8) / 3000 3.36(4.5) / 3600 |
| Direction of rotation | Counterclockwise, facing PTOshaft |
| Fuel | 0# (Summer) / -10# (Winter) |
| Fuel tank capacity (L) | 2.5 |
| Lubricating oil capacity (L) | 0.75 |
| Lubricating system | Pressure splashed |
| Starting system | Manual / Electric start |
| Packing size (L*W*H) mm | 415*385*470 |
| Net weight (KG) | 26 |
Manufacture's Advantages:
1. Our factory was founded in 1981.
2. Main Products: diesel generator sets, generators, engines, water pumps and other agricultural machinery products.
3. We have obtained the relevant certifications such as ISO, CE,ROHS, GS, TUV etc.
Guarantee Service
1. professional value-added technical support
2. warm before-sales & after-sales service
3. warranty period of 24 months or 1200 operating hours for diesel engines.
3. warranty period of 12 months or 1000 operating hours for gasoline engines.
