Low Gas Consumption 50kw Natural Gas Generators with Brushless Electric Start
Low Gas Consumption 50kw Natural Gas Biogas Generator with Brushless Electric Start
Our Services
1. We will answer your questions any time you need.
2. Make OEM service.
3. Each sales will follow your order from begin to the end.
4. Offering indication during installation.
5. Any problem during using will get answer within 24 hours.
6. Free spare parts will be offered if there is any manufacturing problem from our side.
7. Extra spare parts will be offered with cheapest prices.
Nature gas generator feature:
1) No Exhaust Gas,Start quickly in cold region,Lower running cost
2) Gas consumption: less than 0.28cbm/kWh
3) We supply you spare parts during the whole service life.
4) Nature gas generator powered by famous &good quality engine and alternator, such as Cummins, Deutz.
5) Nature gas generator with longer life: nature gas engine has a life of over several years if it is properly operated and maintained
6) Low operation cost of nature gas generator: nature gas has a rich reserve with low cost and a high rate of return
7) High profit of nature gas generator: low operation&maintenance cost, supply of electricity and thermal power at the same time.
8) Nature gas generator coupled with brushless alternators of Leroy Somer /Stamford/ Marathon, etc.
9) Well performed control system, high quality monitor instrument, with sound and light alarm devices, auto shutdown when main power on, auto start when main power off.
10) Protection function: over-current, under-voltage, auto-regulate voltage, reverse power
11) Monitor function: speed, water temperature, lub-oil temperature, lube-oil pressure, exhaust temperature
12) Supply connection: 3 phase, 4 lines
14) Rated frequency: 50Hz / 60Hz
15) Rated power factor: 0.8
16) Exciting way: brushless
17) Starting mode: 24V DC electric starting system
18) Cooling mode: closed-circuit cooling system
China Natural Gas Generator:
| Model | Power | Current (A) |
Engine | Cy. | Bore* Stroke (mm) |
Disp. (L) |
Oil(L) | L×W×H(mm) | Weight (Kg) |
|
| KW | KVA | |||||||||
| LR-30GF | 30 | 37.5 | 54 | CY4102 | 4 | 102×118 | 3.8 | 7 | 2000×750×1300 | 760 |
| LR-50GF | 50 | 62.5 | 90 | HF6105Q | 6 | 105×115 | 3.6 | 15 | 2000×750×1300 | 850 |
| LR-80GF | 80 | 100 | 144 | HF6105ZQ | 6 | 105×115 | 3.6 | 15 | 2200×850×1500 | 1060 |
| LR-100GF | 100 | 125 | 180 | Steyr P10 | 6 | 126×155 | 11.6 | 15 | 2350×900×1650 | 1400 |
| LR-120GF | 120 | 150 | 216 | Steyr P10 | 6 | 126×155 | 11.6 | 15 | 2400×900×1450 | 1700 |
| LR-150GF | 150 | 187.5 | 270 | Steyr P10 | 6 | 126×155 | 11.6 | 15 | 2700×1000×1600 | 2000 |
| LR-220GF | 220 | 275 | 360 | Steyr P12 | 6 | 126×155 | 11.6 | 15 | 3300×980×1900 | 2500 |
| LR-100GF | 100 | 125 | 180 | SC9DT 210D2 |
6 | 114×144 | 8.8 | 24 | 2600×900×1600 | 2200 |
| LR-150GF | 150 | 187.5 | 270 | SC13GT 260D2 |
6 | 135×150 | 12.8 | 34.4 | 2800×1500×2100 | 2500 |
Cummins Natural Gas Generator:
| Model | Power | Current (A) |
Engine Model |
Cy. | Bore* Stroke (mm) |
Disp. (L) |
Oil(L) | L×W×H(mm) | Weight (Kg) |
|
| KW | KVA | |||||||||
| LRC-30 | 30 | 37.5 | 54 | 4B | 4L | 102×120 | 3.9 | 11 | 2000×750×1300 | 760 |
| LRC-40 | 40 | 50 | 72 | 4B | 4L | 102×120 | 3.9 | 11 | 2000×750×1300 | 760 |
| LRC-50 | 50 | 62.5 | 90 | 6B | 4L | 102×120 | 3.9 | 11 | 2000×750×1300 | 850 |
| LRC-60 | 60 | 75 | 108 | 6BT | 6L | 102×120 | 5.9 | 17 | 2200×850×1500 | 1040 |
| LRC-80 | 80 | 100 | 144 | 6BT | 6L | 102×120 | 5.9 | 17 | 2200×850×1500 | 1060 |
| LRC-90 | 90 | 112.5 | 162 | 6BT | 6L | 102×120 | 5.9 | 17 | 2300×850×1500 | 1200 |
| LRC-100 | 100 | 120 | 180 | 6CT | 6L | 114×135 | 8.3 | 17 | 2350×900×1650 | 1400 |
| LRC-120 | 120 | 150 | 216 | 6CT | 6L | 114×135 | 8.3 | 24 | 2400×900×1450 | 1700 |
| LRC-130 | 130 | 162.5 | 234 | 6CT | 6L | 114×135 | 8.3 | 24 | 2500×960×1550 | 1900 |
| LRC-150 | 150 | 187.5 | 270 | 6LT | 6L | 114×135 | 8.9 | 36 | 2700×1000×1600 | 2000 |
| LRC-160 | 160 | 200 | 288 | 6LT | 6L | 125×147 | 11 | 40 | 2850×1060×1760 | 2320 |
| LRC-180 | 180 | 225 | 324 | 6LT8.9 | 6L | 125×147 | 14 | 38 | 3000×1060×1900 | 2450 |
| LRC-200 | 200 | 312.5 | 360 | NT855 | 6L | 125×147 | 14 | 38 | 3300×980×1900 | 2500 |
| LRC-220 | 220 | 275 | 396 | NT855 | 6L | 125×147 | 11 | 40 | 3000×980×1600 | 2450 |
| LRC-250 | 250 | 312.5 | 450 | NT855 | 6L | 140×152 | 14 | 38 | 3300×980×1760 | 2500 |
| LRC-280 | 280 | 350 | 504 | NT855 | 6L | 140×152 | 14 | 38 | 3300×980×1760 | 2600 |
| LRC-300 | 300 | 375 | 540 | KT19 | 6L | 140×152 | 14 | 38 | 3300×980×1760 | 3050 |
| LRC-350 | 350 | 437.5 | 631 | KT19 | 6L | 140×152 | 14 | 38 | 3300×1100×1850 | 3180 |
| LRC-400 | 400 | 500 | 721 | KT19 | 6L | 159×159 | 18.9 | 50 | 3500×1300×1970 | 3500 |
| LRC-440 | 440 | 550 | 792 | KT19 | 6L | 159×159 | 18.9 | 50 | 3500×1300×1970 | 3700 |
| LRC-500 | 500 | 625 | 902 | KT38 | 6L | 159×159 | 18.9 | 50 | 4000×1500×2000 | 4400 |
| LRC-600 | 600 | 750 | 1082 | KT38 | 12V | 159×159 | 37.8 | 135 | 4400×1900×2450 | 7500 |
| LRC-700 | 700 | 875 | 1262 | KT38 | 12V | 159×159 | 37.8 | 135 | 4500×1900×2450 | 7600 |
| LRC-750 | 750 | 937.5 | 1350 | KT38 | 12V | 159×159 | 37.8 | 135 | 4500×1900×2450 | 7850 |
| LRC-800 | 800 | 1000 | 1440 | KT50 | 12V | 159×159 | 37.8 | 135 | 4500×1900×2450 | 7850 |
| LRC-980 | 980 | 1225 | 1764 | KT50 | 12V | 159×159 | 37.8 | 135 | 4500×1900×2450 | 7850 |
| LRC-1100 | 1100 | 1375 | 1984 | KT50 | 16V | 159×159 | 50.3 | 177 | 5300×2200×2600 | 10300 |
Our Advantages:
1,Free Loading Capacity analysis;
2,Free Technology consultations;
3,Free Lay-out of Installation;
4,Free Testing and Debuging;
5,Free Training of Operation;
6,Low cost Spare Parts;
7,1 Year Warranty Service;
8,Life-long maintenance;
9,24 Hours Response;
10,24/7 Service.
