40kW / 50kVA Silent Diesel Power Generator Set 60HZ 4 Cylinders water cooled genset
Price:
Negotiable
MOQ:
1 SET
Delivery Time:
5 - 15days according to the quantity
Brand:
Laurel
Product Description
40kW/50kVA Silent Diesel Generator Set 60HZ 4-Cylinders water cooled genset
1. Specification of genset
| Gensets model | LF50Y6 | ||||||||
| Prime power | 40KW/50KVA | ||||||||
| Rated Voltage(V) | 440/220 | ||||||||
| Rated frequency(HZ) | 60 | ||||||||
| Rated Speed(RPM) | 1800 | ||||||||
| Power Factor | 0.8(lagging) | ||||||||
| Dimensions(mm) (L×W×H) | 2000x950x1100 | Open type | |||||||
| Genset Weight(kg) | 750 | ||||||||
| Dimensions(mm) (L×W×H) | 2400x1000x1560 | Silent type | |||||||
| Genset Weight(kg) | 1250 | ||||||||
2. Specification of diesel engine
| Engine brand | YTO | ||||||||
| Engine model | Y4105D | ||||||||
| Output power | 42.9kW/53.6kVA | ||||||||
| Number of Cylinders | 4 | ||||||||
| Cylinder arrangement | In-line | ||||||||
| Cycle | Four stroke | ||||||||
| Aspiration | Aspiration | ||||||||
| Bore×Stroke (mm×mm) | 102 x 118 | ||||||||
| Displacement (Liter) | 4.33 | ||||||||
| Compression Ratio | 18.0:1 | ||||||||
| Speed Governor | Mechanical | ||||||||
| Cooling System | Forced Water Cooling Cycle | ||||||||
| Total lubrication system capacity (L) | 16 | ||||||||
| Fuel Consumption at 100% Load (g/kw.h) | 223 | ||||||||
| Starting Method | DC24V electrical starting |
3. Specification of alternator
| Alternator brand | Stamford | ||||||||
| Alternator model | PI1 44K | ||||||||
| Rated power | 40KW/50KVA | ||||||||
| Number of Phase | 3 | ||||||||
| Connecting Type | 3 Phase and 4 Wires | ||||||||
| Number of Bearing | 1 | ||||||||
| Protection Grade | IP23 | ||||||||
| Altitude | ≤1000m | ||||||||
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | ||||||||
| Insulation Class | H | ||||||||
| Telephone Influence Factor (TIF) | ≤50 | ||||||||
| THF | ≤2% | ||||||||
| Voltage Regulation, Steady State | ≤±1% | ||||||||
| Transient State Voltage |
≤-15%~+20% |
