12 Cylinders 500 kVA Open Diesel Generator Rain Proof Industrial Diesel Generator Set
12 Cylinders 500kVA Diesel Generator Set with China Shangchai Engine , Rain Proof Available
Product Description:
This Generator are equipped with Dongfeng135 series diesel engine that offered by
Shanghai Diesel Engine Co.,Ltd.
The 135 series,is the model what developed in the earliest period and widely used in
China,possesses the advantages of mature technology,easy parts purchasing and large range of power.
The type includes in-line 4 cylinders,6 cylinders,V 12 cylinders,and the power is from 40kw-500kw so as to meet differentusers' demands.It will be the first choice with perfect power performance,more economic and lower operation cost.
1. Gen-set
| The model of the unit: | LF-400GF-1 |
| Power: | 500KVA |
| Rated voltage: | 400V/230V |
| Rated current: | 720A(adjustable) |
| Rated frequency: | 50Hz/60Hz |
| The factor of rated power | COS=0.8(lag) |
| The regulating rate of steady voltage: | ≤±0.5% |
| The regulating rate of instantaneous voltage: | ≤-10%/ +20% |
| The time of steady voltage: | ≤1.5sec |
| The waving rate of voltage: | ≤8% |
| The regulating rate of steady frequency: | ≤3% |
| The regulating rate of instantaneous frequency: | ≤10% |
| The time of steady frequency: | 3sec |
| The waving rate of frequency: | ≤0.25% |
| The waste of fuel with full load: | 225g/kw/h |
| size(mm): | 3400*1500*1950 |
| weight: | 4200KG |
2. Engine
| Brand: | Shangchai | |
| Model: | 12V135BZLD | |
| Type: | four strokes, waste gas turbine boost,direct spurting type | |
| Cooling way: | water cooling | |
| With Type: | V type | |
| Bore *Trip : | 135mm*150mm | |
| Displacement | 26.8L | |
| Lubricating oil capacity: | 57L | |
| Cylinder: | 12cylinders | |
| Rotating speed: | 1500r/min or 1800r/min | |
| The regulation of rotating speed: | Electronic speed | |
| Starting way: | DC24V starting with electricity | |
3.Alternator
| Brand: | ComAp,Stamford,Marathon |
| Type: | brushless (AVR automatic voltage regulating) |
| The connecting way of the phase: | three phases four lines |
| Insulation degree: | H degree |
| Grading Protection: | IP22/IP23 |
FAQ
1.What's the power range of diesel generators?
Power range from 5kva~3000kva.
2.What's the delivery time?
Delivery within 7 days after deposit confirmed.
3.What's your payment term?
1.We accept 30% T/T as the deposit,the balance payment paid before delivery
2. L/C at sight
4.What's your warranty?
Warranty is one year or 1000 hours which comes first.
5.What's your MOQ?
MOQ is 1 set.
6.What's the frequency of diesel generators?
50/60HZ
7.What's the voltage of your diesel generator?
Voltage available 220/380V,230/400V,240/415V, just as per your request.
