2 Inch Diesel Agricultural Water Pump 4HP 170F Engine Key Starter / Recoil Starter
2 Inch Diesel Water Pump with 4HP 170F Engine with Key Starter / Recoil Starter
Specifications:
2 inch outlet/inlet
lift is 22m
4.0hp diesel engine power
212cc ,key starter/recoil starter
Data:
| Model | LP50ZB22-2.5C | LP80ZB22-2.5C | LP100ZB25-3.5C | |
| Pump |
Inlet Size(mm) | 50 | 80 | 100 |
| Outlet size(mm) | 50 | 80 | 100 | |
| Specified point of flux(m3/h) | 20 | 45 | 78 | |
| Lift(m) | 22 | 22 | 25 | |
| Suction(m) | 5 | 5 | 5 | |
| Rotation Speed(rpm) | 3600 | 3600 | 3600 | |
| Diesel Engine |
Engine Model | LE170FG | LE170FG | LE178FG |
| Bore x Stroke | 70mmx55mm | 70mmx55mm | 78mmx62mm | |
| Horse Power | 4hp | 4hp | 6hp | |
| Displacement | 211ml | 211ml | 296ml | |
| Compression Ratio | 20:01 | 20:01 | 20:01 | |
| Rated Power | 2.3kw/3000min | 2.3kw/3000min | 4.0kw/3000min | |
| Idling Speed | 1300rpm | 1300rpm | 1300rpm | |
| Oil Injection Pressure | 20±0.5MPa | 20±0.5MPa | 20±0.5MPa | |
| Fuel Tank Capacity | 2.52L | 2.52L | 3.5L | |
| Fuel Consumption | 280.2g/kw.h | 280.2g/kw.h | 286g/kw.h | |
| Continuous Running Time | 3h | 3h | 2.4h | |
| Engine Oil Capacity | 0.75L | 0.75L | 1.3L | |
| Fuel Number | 0#;-10#;-20# | 0#;-10#;-20# | 0#;-10#;-20# | |
| Engine Oil Number | 10W/30;15W/40 | 10W/30;15W/40 | 10W/30;15W/40 | |
| Packing Detail |
N.W/G.W(kg) | 31/34 | 35/38 | 52/55 |
| Dimension(L×W×H)mm | 490×450×425 | 560×450×475 | 680×520×660 | |
| 20Q | 295Unites | 250Unites | ||
| 40HQ | 720Unites | 525Unites |
Advantages:
1. Reliable Performance:
Reliable Performance is the major advantage of products, and this reliability is based on the outstanding design in every aspect and strict Q.C. System.
2. Customer First:
We devote ourselves to develop products to meet customers' requirements .Our engineer develop and
design new products for customers.
3. Strict test process before ex-factory:
Every product will be tested twice before ex-factory,and our products are 100% ex factory pass rate.
4. Low fuel consumption, easy maintenance
5. Certification: CE,ISO,GS,SONCAP etc.
6.Our logo or OEM
