Soundproof AC Three Phase Cummins Diesel Generator , 37.8L Displacement Brushless AVR
Soundproof 825kVA AC Three Phase Cummins Diesel Generator , 37.8L Displacement Brushless AVR
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client's request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
Specification of generator:
| Genset Model | LF825 | LF880 | LF000 | LF1100 | LF1250 | LF1375 | LF1500 | LF1650 | LF1718 | |
| Rated Power |
KW/ KVA |
600/ 750 |
640/ 800 |
728/ 910 |
800/ 1000 |
900/ 1125 |
1000/ 1250 |
1100/ 1375 |
1200/ 1500 |
1250/ 1560 |
| Standby Power |
KW/ KVA |
660/ 825 |
704/ 880 |
800/ 1000 |
880/ 1100 |
1000/ 1250 |
1100/ 1375 |
1200/ 1500 |
1320/ 1650 |
1375/ 1718 |
| Rated Voltage | V | 220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V | ||||||||
| Speed | RPM | 1500/1800 | ||||||||
| Rated frequ ency |
Hz | 50/60 | ||||||||
| Engine Model | KTA38 -GA |
KTA38 -G2B |
KTA38 -G2A |
KTA38 -G5 |
KTA38 -G9 |
KTA50 -G3 |
KTA50 -G8 |
KTA50 -GS8 |
KTA50 -G9 |
|
| Engine Power | KW | 711 | 789 | 895 | 970 | 1089 | 1227 | 1429 | 1429 | 1656 |
| Air intake way |
Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | |
| Governor | Electronic | |||||||||
| Cylinder | QTY | 12 | 12 | 12 | 12 | 12 | 16 | 16 | 16 | 16 |
| Bore* Stroke |
mm *mm |
159 ×159 |
159 ×159 |
159 ×159 |
159 ×159 |
159 ×159 |
159 ×159 |
159 ×159 |
159 ×159 |
159 ×159 |
| Displa cement |
L | 37.8 | 37.8 | 37.8 | 37.8 | 37.8 | 50.3 | 50.3 | 50.3 | 50.3 |
| Fuel Consu mption |
g/ kw.h |
199 | 199 | 199 | 202 | 199 | 197 | 205 | 204 | 203 |
| Comp ression Ratio |
14.5:1 | 14.5:1 | 14.5:1 | 13.9:1 | 13.9:1 | 13.9:1 | 14.9:1 | 14.9:1 | 13.9:1 | |
| Alternator Model | LA- 634B |
LA- 634C |
LA- 634D |
LA- 634E |
LA- 634F |
LA- 634G |
LA- 734B |
LA- 734B |
LA- 734C |
|
| Voltage Regulation | AVR | |||||||||
| Excitation Method | Brushless | |||||||||
| Open Type Size |
mm |
4000x 1600 x2250 |
4000x 1600 x2250 |
4300x 1600 x2250 |
4670x 1750 x2250 |
4800x 2000 x2320 |
4850x 2000 x2320 |
4980x 2000 x2350 |
4980x 2000 x2350 |
5200x 2150 x2400 |
| Open Type Weight |
kg | 4260 | 4400 | 5800 | 6000 | 7600 | 7800 | 8200 | 9500 | 10000 |
| Sound proof Size |
mm |
4800* 2200 *2600 |
4800x 2200 x2600 |
5600x 2200 x2600 |
5800x 2200 x2600 |
6000x 2200 x2600 |
6000x 2200 x2600 |
6000x 2200 x2600 |
6000x 2200 x2600 |
7000x 2300 x2650 |
| Sound proof Weight |
kg | 5900 | 6100 | 7950 | 8300 | 9660 | 9800 | 10800 | 12300 | 13600 |
Product Features:
(1).Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.
(8).50Hz and 60Hz both are available for choice
