Diesel Power Water Cooled Cummins Diesel Generator 1375kw CE Certificate 1718kVA
CE Certificate 1718kVA Diesel Power Water Cooled Cummins Diesel Generator 1375kw
Product Detail of Diesel Generator Set
1. Powered by CUMMINS diesel engine.
2. Radiator and fan with safety guard
3. Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR.
4. Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.
5. Extemal recessed emergency stop button for extra safety.
6. Strong and durable hi-strength base frame
7. Built-in shock pad
8. Optional voltage rank: 230V/400V, 220V/380V, 127V/220V, 240V/480V etc
Specification of generator:
| Genset Model | LF825 | LF880 | LF1000 | LF1100 | LF1250 | LF1375 | LF1500 | LF1650 | LF1718 | |
| Rated Power |
KW/ KVA |
600/ 750 |
640/ 800 |
728/ 910 |
800/ 1000 |
900/ 1125 |
1000/ 1250 |
1100/ 1375 |
1200/ 1500 |
1250/ 1560 |
| Standby Power |
KW/ KVA |
660/ 825 |
704/ 880 |
800/ 1000 |
880/ 1100 |
1000/ 1250 |
1100/ 1375 |
1200/ 1500 |
1320/ 1650 |
1375/ 1718 |
| Rated Voltage | V | 220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V | ||||||||
| Speed | RPM | 1500/1800 | ||||||||
| Rated frequency | Hz | 50/60 | ||||||||
| Engine Model | KTA38 -GA |
KTA38 -G2B |
KTA38 -G2A |
KTA38 -G5 |
KTA38 -G9 |
KTA50 -G3 |
KTA50 -G8 |
KTA50 -GS8 |
KTA50 -G9 |
|
| Engine Power | KW | 711 | 789 | 895 | 970 | 1089 | 1227 | 1429 | 1429 | 1656 |
| Air intake way | Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | Turbo | |
| Governor | Electronic | |||||||||
| Cylinder | QTY | 12 | 12 | 12 | 12 | 12 | 16 | 16 | 16 | 16 |
| Bore*Stroke |
mm *mm |
159×159 | 159×159 | 159×159 | 159×159 | 159×159 | 159×159 | 159×159 | 159×159 | 159×159 |
| Displacement | L | 37.8 | 37.8 | 37.8 | 37.8 | 37.8 | 50.3 | 50.3 | 50.3 | 50.3 |
| Fuel Consumption |
g/ kw.h |
199 | 199 | 199 | 202 | 199 | 197 | 205 | 204 | 203 |
| Compression Ratio | 14.5:1 | 14.5:1 | 14.5:1 | 13.9:1 | 13.9:1 | 13.9:1 | 14.9:1 | 14.9:1 | 13.9:1 | |
| Alternator Model | LA-634B | LA-634C | LA-634D | LA-634E | LA-634F | LA-634G | LA-734B | LA-734B | LA-734C | |
| Voltage Regulation | AVR | |||||||||
| Excitation Method | Brushless | |||||||||
| Open Type Size | mm |
4000x 1600 x2250 |
4000x 1600 x2250 |
4300x 1600 x2250 |
4670x 1750 x2250 |
4800x 2000 x2320 |
4850x 2000 x2320 |
4980x 2000 x2350 |
4980x 2000 x2350 |
5200x 2150 x2400 |
| Open Type Weight | kg | 4260 | 4400 | 5800 | 6000 | 7600 | 7800 | 8200 | 9500 | 10000 |
| Soundproof Size | mm |
4800x 2200 x2600 |
4800x 2200 x2600 |
5600x 2200 x2600 |
5800x 2200 x2600 |
6000x 2200 x2600 |
6000x 2200 x2600 |
6000x 2200 x2600 |
6000x 2200 x2600 |
7000x 2300 x2650 |
| Soundproof Weight | kg | 5900 | 6100 | 7950 | 8300 | 9660 | 9800 | 10800 | 12300 | 13600 |
Our Services
1. Products and services all comply with ISO9001 and GB/T2820 manufacturing standards.
2. Management is implemented in strict accordance with ISO9001 Quality
3. Management System and ISO14001
4. Environmental Management System.
5. All products have passed rigorous factory test to ensure high quality.
6. Product warranty terms are strictly enforced.
7. High-efficiency assembly and production lines ensure on-time delivery.
8. Professional, timely, thoughtful and dedicated services are offered.
9. Favorable and complete original accessories are supplied.
