Industrial 280 kw Silent Diesel Cummins Generator Water Cooled 3 Phase 50Hz
AC Power 280kw Silent Diesel Cummins Generator for Industrial Water Cooled 3 Phase 50Hz
Performance Feature:
1. Engine and alternator shall be mounted on a same frame steel skid.
2. Built-in damper for anti-vibration.
3. Small size, low weight, easy for operation, installation and maintenance.
4. World most famous brand diesel engine.
CUMMINS, PERKINS, VOLVO PENTA, DOOSAN, DEUTZ
5. World famous brand AC alternator: Stamford,MECC, Kaijieli
6. Advanced and reliable controller: Key start, Auto start, AMF & Remote control by PC with RS232 / 485.
Testing Items of Power Friend Genset:
1) Parts fault testing
2) Fue tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insultion testing
6) Noise testing
7) Loading testing: All qualified generator sets are subjected to a comprehensive performance test which inclides 0% load, 25% load, 50% load, 75% load, 100% load and 110% load and to check, verify that all control systems, alarm and shut-own protection.
Guarantee:
1) Guarantee Period: One year or 1000 running hours, depends on whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent by air express.
4) 24 hours service hotline is available for customers.
Technical parameters of diesel generator sets:
| Generator Set | |
| Generator Model | LF280C |
| Prime Power | 280KW |
| Rated Voltage | 400/230V |
| Frequency | 50Hz |
| Power Factor | 0.8(lagging) |
| Genset weight | 2640 kg |
| Dimension | 3100*1110*1820mm |
| Diesel Engine | |
| Brand | Laurel |
| Prime Power | 308kw |
| Type | NTA855-G2A |
| Cylinders/Arrangement | 6/L |
| Rotating Speed | 1500RPM |
| Cycle | Four stroke |
| Aspiration | Turbocharged after water-cooled |
| Boke×Stroke | 140*152mm |
| Speed Governor | Electrical |
| Cooling System | Water-cooled |
| Consumption of fuel | 72 L/H |
| Lub.oil Cap | 38.6L |
| Coolant Cap | 61L |
| Starting Method | 24V Electrical starting |
| Alternator | |
| Brand | Laurel |
| Model | LA280 |
| Prime/Standby Power | 280/308kw |
| Connecting Type | 3 Phase and 4 Wires |
| Number of Bearing | single |
| Protection Grade | IP23 |
| Exciter Type | Brushless ,Self-exciting, AVR automatic voltage regulating |
| Insulation Class | H |
| Telephone Influence Factor (TIF) | ≤50 |
| THF | ≤2% |
| Voltage Regulation, Steady State | ≤±0.5% |
| Transient State Voltage | ≤-15%~+20% |
Our Service
1. OEM Manufacturing welcome: Product, Package
2. We will reply you for your inquiry in 24 hours.
3. After sending, we will track the products for you frequently, until you get the products. When you got the generator, test it, and give me your feedback.If you have any questions about the problem, contact with us, we will offer you the solution ASAP.
4. Each category generator of our company can share 12 months or 1000 working hours maintenance which occurs first.
5. We are responsible for all malfunctions arising from structural defect of generator set itself. Wearing parts, daily used consumable parts and destroyed parts by wrong operation or maintenance ignorance are not in the range of quality guarantee.
