50Hz / 60Hz Air Cooling 4 Stroke 5.5kw Diesel Driven Generator Good Performance
50Hz /60Hz Air Cooling 4 Stroke 5.5kw Electric Diesel Generator Good Performance
Product Advantages:
♦ Use good brand 5KVA spare parts, major product, stable quality alternator generator
♦ Have 130*190mm and 140*190mm alternator, make the rated output 4.6KW and 5KW.
♦ Portable type mobile power generator, with four wheels, easy to move for home or outside use
♦ We are 5KVA generator factory, have low price spare parts and timely technical support.
♦ 100% copper alternator, real technical data for customers.
♦ Many kinds and different power generator, different color for your choice, welcome your inquiry.
Generator Strength:
1. Supply you top quality products with competitive price under the same quality level, different products according to your different market demands.
2. Strictly control the whole production process and guarantee punctual delivery, Test each of our products one by one before packing to ensure the quality.
3. Supply you a good pre-sale, in-sale and after-sale service, We're not just working partners, but also friends and family.
4. When you come to our factory, we will try our best to supply you all services to make you feel like at home.
Generator Data:
| Model | LR5000DS-6 | LR6500DS-6 | LR7500DS-6 | LR8500DS-6 | |
| Generator | Rated voltage | 110,120,220,230,240,220/380 | |||
| Frequency | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | |
| D. C. Output | 12V 8.3A | 12V 8.3A | 12V 8.3A | 12V 8.3A | |
| How Many Output | 2 | 2 | 2 | 2 | |
| Rated power output (KVA) |
4.2/4.6 | 4.5/5.0 | 5.0/5.5 | 6.0/6.5 | |
| Max. power output (KVA) |
4.6/6.0 | 5.0/5.5 | 5.5/6.0 | 6.5/7.0 | |
| Engine | Type | Air-cooled, single cylinder, 4-stroke | |||
| Engine Model | LE186FE | LE186FAE | LE188FBE | LE192FE | |
| Displacement | 406cc | 418cc | 456cc | 498cc | |
| Bore*Stroke(mm) | 86*70mm | 86*72mm | 88*75mm | 92*75mm | |
| Recommend Fuel | Diesel | Diesel | Diesel | Diesel | |
| Fuel tank capacity | 15L | 15L | 12.5L | 12.5L | |
| Continous operating hour |
9.5 | 9.5 | 5.5/5.0 | 5.0/4.5 | |
| Noise (7m away) | 70dba | 70dba | 70dba | 70dba | |
| Starting System | Electric | Electric | Electric | Electric | |
| Options | Voltmeter | Y | Y | Y | Y |
| Digital display screen |
Optional | Optional | Optional | Optional | |
| ATS | Optional | Optional | Optional | Optional | |
| Remote Controller | Optional | Optional | Optional | Optional | |
| Net weight | 165kg | 165kg | 165kg | 165kg | |
| Packing size | 955*545*710 mm |
955*545*710 mm |
955*545*710 mm |
955*545*710 mm |
|
Application
For social activities:
education, training and culture school or institution, medical centre, clinique, organization and government department, religion centre, entertainment and sport centre
For business activities:
shops, restaurants, workshops, hotels, offices, farms
For residential:
Villa area, residence community, activity outdoors
Our main products:
We are engaged in the production and sale of diesel generator sets, generators, engines, water pumps and other agricultural machinery products. We have obtained the relevant certifications such as ISO, CE,ROHS, GS, TUV etc.
Guarantee Service
We have 35 years of export experience. We deliver not only our products, but also our value-added technical support and after-sales service. We ensure that all our original purchasers get Laurel & Honesty Holdings products guarantee under this warranty statement.
Warranty Period
We will provide a warranty period of 24 months or 1200 operating hours to the original purchasers for all our Diesel associated products, and a warranty period of 12 months or 1000 operating hours to the original purchasers for all gasoline associated products. The warranty period starts from the day of delivery to the original retail purchaser.
