50Hz Open Type Water Cooling 400 V Diesel Generator Set By 664kW Copy Stamford Engine
50Hz Open type water cooling 400 V Diesel Generator Set by 664kW Copy Stamford engine
Engine Feature for Cummins diesel generator 600kw
1.Diesel, heavy-duty, four stroke, water cooled and direct injection fuel system
2.24/12V D.C starter and charger alternator
3.Industrial capacity exhaust silencer supplied loose with flexible section
4.Engine driven cooling fan with protection guard
5.Steel wire braided fuel lines, vent and rain fittings
6.Set mounted acid battery installed with leads and terminals
Control System for Cummins diesel generator 600kw
1.manual / auto start and protection module
2.Equipped with Deep Sea,ComAp,Harsen,Smartgen famous control systems.
3.New integrated controllers in manual and remote start application.
4.Featuring full gen-set monitoring and protection.
5.Powerful graphic display, Icons, symbols and bar graphs.
Genset specification:
| Genset Model | LF600 |
| Engine Model | KTA38-G2 |
| Alternator Model | KHI600 |
| Rated Power | 600 kW |
| Voltage | 400 V |
| Speed | 1500 RPM |
| Cooling Method | Fan Radiator |
| Diemension (L×W×H) | 4350×1630×2450MM |
| Weight | 4200 KG |
| Certificate | ISO9001 |
| Specification of diesel engine | |
| Engine Model | KTA38-G2 |
| Rated power | 664kW |
| Cylinders | 12V |
| Bore×Stroke | 159×159mm |
| Cycle | Four stroke |
| Displacement | 37.8L |
| Compression Ratio | 15.5:1 |
| Speed Governor | Electrical |
| Cooling system | Force water cooling cycle |
| Fuel Consumption at 100% Load | ≤208(g/kw.h) |
| Start Method | DC24V Electrical |
| Specification of Alternator | |
| Alternator Brand | Copy Stamford(Stamford is optional) |
| Alternator Model | KHI600 |
| Rated Power | 600kW |
| Connecting Type | 3 phase 4 wires |
| Protection Grade | IP23 |
| Insulation Class | H |
| Exciter Type | Brushless ,Self-exciting,AVR automatic voltage regulating,100% Copper winding wire |
FAQ
1.What's your power range of diesel generators?
Answer: We can offer the range from 10kva~3000kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 7 days after we get the deposit.
3.What's your payment?
Answer: We accept T/T, L/C,and 30% T/T as the deposit,the balance payment should be
paid before shipping.
4.What's your warranty?
Answer: All our products we offer on year warranty or 1000 hours which comes first.
5.What's your MOQ?
Answer:We accept the MOQ is 1 set.
6.What's the frequency of diesel generators?
Answer: 50/60HZ
7.Do you have single phase or three phase diesel generators?
Answer: Yes,we have single phase and three phase diesel generators.
8.What's the voltage of your diesel generator?
Answer:Generally,the voltage is 220/380V,230/400V,240/415V or according to your requests.
Our main products:
We are engaged in the production and sale of diesel generator sets, generators, engines, water pumps and other agricultural machinery products. We have obtained the relevant certifications such as ISO, CE,ROHS, GS, TUV etc.
Guarantee Service
We have 35 years of export experience. We deliver not only our products, but also our value-added technical support and after-sales service. We ensure that all our original purchasers get Laurel & Honesty Holdings products guarantee under this warranty statement.
