Hinge Durability Tester Furniture Testing Machines With DIN 68857 and QB/T 2189 Standard
Manufactured Goods Hinge Durability Tester With DIN 68857 and QB/T 2189 Standard
Description:
Hinge Durability Tester is suitable to test goblet dark hinge and its installed base capability.Install a
couple hinge on the tester and test door,test the shut force,durability,resistance to overranging.Control
cabinet: Electric control components and control panel. Power sensor, sense the strength of shut force
and resistance to overranging.
Specifications:
| Model | TNJ-027 |
| Sample | two hinges B type |
| Size | 64x60x100 cm |
| weigh | 6kg |
| Durability test | 40000 times, 18 times/min |
| Weigh | 65Kg |
| force value | 50N |
| Power | 1∮ AC 220V 50Hz 3A |
| Transfinite test | 5 times |
| Standard | DIN 68857 and QB/T 2189 |
