Electronic Tensile Testing Machine with Multiple Clamps Force And Elongation Display
Electronic Tensile Testing Machine Multiple Clamps Force And Elongation Display
Description:
This machine is suitable for all kinds of textile, rubber, plastic, synthetic leather, adhesive tape, electro-nic, metal industries such as materials and products tensile, tear, peel, test, to determine the quality of
the product.
Advantages:
1. Speciality in testing equipment
2. Various products to choose from
3. Accept customization
4. Excellent after-sale service
Specifications:
|
Capacity choice |
1, 2, 5, 10, 20, 50, 100, 200 kg optional |
|
Stroke |
850 mm (contain clamps) |
|
Range of speed |
50 ~ 300 mm/min adjustable, constant speed 300 mm/min |
|
Force relative error |
± 0.5 % |
|
Displacement relative error |
± 1.0 % |
|
Test speed relative error |
± 1.0 % |
|
Resolution |
1/100,000 |
|
Motor |
adjustable speed motor |
|
Display |
force and elongation display |
|
Dimension |
(W * D * H) 50 * 50 * 120cm |
|
Optional accessories |
stretcher, air clamp |
|
Weight |
60 kg |
|
Power |
1 PH, AC 220 V, 50/60 Hz |
