Lab Big Lcd Touch Screen Single-arm Tensile Test Machine
HTP-001A Big LCD Control Screen Single-arm Tensile Testing Machine
Description:
This machine can widely apply to a variety of different textile materials and wood, shoes, tires, leather, tannery,rubber tubes, triangular tape, plastic sheeting, plastic sheeting, packaging films, acrylic, FRP, ABS, EVA, PV and other products, semi-or dumbbell-shaped specimens of the tensile strength, elongation, tear, glue focused, tensile stress, peel, shear, the sticky relay of rubber and metal by using different fixtures
Advantages:
1. Speciality in testing equipment
2. Various products to choose from
3. Accept customization
4. Excellent after-sale service
Specifications:
| Capacity | 200KG (2,5,10,20,50,100,200kg for option) |
| Load accuracy | ±0.5％ of value |
| Display | LCD English version, touch key |
| Units | Kg,lb,N |
| Data sampling frequency | 200times/sec |
| Load solution | 1/±25000 of max load |
| Load sensor | Pull and press sensor(max load) |
| effective test width | 150mm |
| Max stroke | 1000mm (650mm /800mm for option) |
| Test speed | 50-300mm/min stepless speed and 5 steps constant speed |
| Displacement accuracy | ±0.5％ |
| Breakpoint ratio | 0～99％,users could set the right breakpoint time according to different test materials |
| Safety device | Up and down stroke limit device |
| Overload protection | If 10％ over than max load,machine will automatic stop for protection |
| Result print | Built in Micro thermal printer |
| Grip | tensile fixture 1 set |
| Machine Size | 450×500×1400mm |
| Machine weight | Approx 60 Kg |
| Power | 220V/50Hz |
Standard:
GB,ISO7500/1,JJG475-88,ASTME4,DIN5122,JISB7721/B7733,EN1002-2,BS1610,CNS9471/9470
