Fully Automatic Fabric Air Permeability Tester ASTM D737 Approved

Applicable Range:

Used for testing the air permeability of various textile fabrics, textile manufactures, including industrial fabrics, nonwoven fabrics and other materials permeable to air.

Technical parameters:

Measuring Unit: mm/s,L/m2/s,cm3/cm2/s,dm/min,L/dm2/min,m/min,m/h,cfm

Test Accuracy better than ±2％

Test Pressure: 0-1000Pa for sample, 0-4000Pa for Nozzle

Air permeability: 0.2～13000mm/s

Measuring error:≤±2％

Fabric thickness could be: ≤15mm

Air regulation:data feedback dynamic regulation

Test Area &Test fixture: 20cm² and 38c㎡(Ø 70mm) ;

Output: inside stylus printer

Power Source: 220V±10% , 50Hz, 800W

External Dimension: 520×850×1050mm

Pore plate (nozzle): 8 pcs, automatically changeable by machine, no need to change it by hand

Net weight: 55Kg

Applicable standards: ASTM D737-2018,GB/T5453 GB/T13764 ISO9237 ISO7231 ISO5636 BS5636 DIN 53887
JIS L1096 BS5636
