Retractable 100% Duty Rated Hydraulic Rising Bollards Electric Hydraulic Mechanically Operated
Price:
US$250~US$350
MOQ:
Sample order accepted
Delivery Time:
5-7 working days after payment received
Brand:
SINOMATIC
Product Description
Retractable Hydraulic Rising Bollard System
SINOMATIC hydraulic Rising Bollard is an electric-hydraulic-mechanically operated retractable bollard system designed for quick and easy operation. Suitable for both security and access control applications, this system provides perimeter security while maintaining environmental aesthetics.
Key Features
- Stainless steel anti-collision, fully automatic lifting column
- Thick material construction with waterproof design and night reflectivity
- One-click remote control with automatic lifting and lowering
- Support for multiple linked switches
- Stable and durable construction with branded motor
Hydraulic Bollard Advantages
- Embedded motor and hydraulic pump with 220V supply, underground installation with waterproof function
- Peripheral embedded parts with bottom drainage holes for effective water management
- Long service life exceeding 10 years, superior to traditional electric and pneumatic bollards
- Steel track construction for enhanced anti-crash capability and stability
- Stainless steel material with reinforced hydraulic system, weighing 160kg for maximum durability
Customization & Service Options
- Multiple steel thickness options available (default 6mm)
- Various color customization options
- Custom sizing to meet specific requirements
- OMRON PLC control system for steady and safe operation
- Fast rising time with durable hydraulic pressure system
- Durable stainless galvanization housing
- Optimized frame structure with high anti-impact and loading capabilities
- High security and anti-collision ability
- Reflective band with low-energy LED lighting for night visibility
Technical Specifications
| Bollard Color | Stainless steel original color |
| Raising/Lowering Speed | ≤4S/≤2S |
| Diameter | 219mm (168mm, 273mm, 324mm optional) |
| Raised Height | 600 |
| Material | SS304/SS316 |
| Control Mode | Remote control (<50m) |
| System Control | Hydraulic and electric control |
| Working Temperature | -30℃～+75℃ |
| Embedded Cylinder Depth | 800mm |
| Lamp Band | LED light (Acrylic light circle) |
| Power Supply | 220V |
| Thickness | 6mm/8mm/10mm/15mm/20mm |
| Weight | 60~120kg |
| Anti-collision Levels | K4,K8,K12 |
| Service Life | 5 million cycles |
| Drainage Mode | Natural drainage + External drainage system |
Automatic Bollard Features
High security and anti-collision capability with pneumatic air pump providing sustained power. Electronic control enables automatic rise/fall functionality with high system independence.
Reflective Band Options
Various color options available for Glossee aveolate reflective band, requiring minimal light for clear night visibility.
Available Materials
304 stainless steel, 316 stainless steel, and carbon steel with electrophoresis spray paint.
Flange Design
Anti-skid flange with unique pattern design compatible with various road surfaces. Built-in PA orientation for precise alignment.
Top Cap Integration
Simple integration design compatible with all architectural styles. Excellent workmanship provides resistance to close attacks.
Case Reference
About SINOMATIC Company
Founded in 2002, SINOMATIC is a national high-tech enterprise specializing in R&D, production, and sales of intelligent access control products. With nearly 200 patented technologies, our product range includes access control turnstiles, parking barrier gates, automatic gate openers, and anti-terrorism roadblocks for government buildings, commercial plazas, residential areas, stations, and customs checkpoints.
SINOMATIC maintains strong innovation capabilities and leads the industry in intelligent variable speed interconnection technology. Our products are distributed globally with service outlets in over 150 countries including United States, Canada, UK, France, Germany, Russia, India, and many others.
