1.2mm SS304 Tripod Turnstile Gate with 0.2S Self Resetting and Dry Contact for Access Control
Price:
negotiable
MOQ:
Sample order accepted
Delivery Time:
5-10 working days after payment received
Brand:
SINOMATIC
Product Description
1.2mm SS304 Ticket Tripod Turnstile Gate with 0.2S Self Resetting Dry Contact
Product Overview
Our tripod turnstile series represents intelligent passage management equipment that integrates precision mechanical transmission, microprocessor control, and various read/write technologies. Designed for comprehensive access control, this system effectively manages personnel flow when equipped with compatible read/write devices.
Technical Specifications
| Model | SN-TT03 |
| Size | 1200×280×980mm |
| Material | 1.2mm SS304 Stainless Steel |
| Pass Width | 550mm |
| Passage Direction | Single Directional/Bi-directional |
| Pass Rate | 30-35 persons/minute |
| Operating Time | 0.2 seconds |
| Power Input | AC100-240V, 50/60HZ |
| Working Voltage | 24V |
| Working Humidity | 30%~95% |
| Working Temperature | -20℃ to +60℃ |
| Working Environment | Indoor/Outdoor |
| Communication Interface | Dry Contact |
| Mechanism | Mould Machine Core + Mould Bracket + Domestic Solenoid |
Key Features & Functions
- Smooth operation with minimal noise and no mechanical impact
- Semi-automatic mechanism requiring no maintenance
- Self-diagnostic failure detection with alarm indication
- Multiple operation modes for flexible access control
- Automatic arm drop function during power failure
- Standard electrical interface for easy system integration
- Card reading with or without memory capability
- Self-resetting function cancels access rights if card is read but not used
- Direction indicator showing passage status
- Anti-reverse passing protection with configurable lock time
- Anti-illegal passing prevention with card-based unlocking
- Anti-collision safety feature with automatic reset
Applications
- Office Buildings & Government Facilities
- Educational & Research Institutions
- Commercial Establishments: Supermarkets, Malls, Hotels, Banks
- Entertainment Venues: Parks, Amusement Parks, Tourist Attractions
- Transportation Hubs: Bus Stations, Railway Stations, Airports, Subways
Construction: Crafted from 1.2mm SS304 stainless steel with a pleasing aesthetic, the turnstile offers durability and corrosion resistance. The system includes a specialized fire control interface for emergency evacuation scenarios, ensuring rapid arm release during critical situations.
