Silent Open Diesel Portable Generator Set 1.7KVA-2.6KVA 50HZ 60HZ
Silent / Open Diesel Generator Set 1.7KVA - 2.6KVA Portable Genset 50HZ / 60HZ
Features and Benefits
1. Powerful Lees four-stroke engine
Lees commercial-grade OHV engines are reliable, easy-to-start and incredibly rugged.
2. Reliable and stable output
Applied the improved AVR (automatic voltage regulator), which not only
can smooth the output but also provide reasonable protection against
the overload of the whole set
3. Competitive economic operation
The high efficiency combustion system is designed to reduce the
consumption and operation cost
4. Qualified breaker, electronic elements
Ensuring high quality of generator, protect the generator from being overload
5. Compact design
Provides unparalleled power to weight ratio
6. Large steel fuel tank
For durability and extended running time
Technical Specifications:
|
Frequency(Hz) |
50 |
60 |
|
|
Rated Output(kVA) |
4.5 |
5.0 |
|
|
Max Output(kVA) |
5.0 |
5.5 |
|
|
Voltage(V) |
220 |
220 |
|
|
Current(A) |
19.9 |
23 |
|
|
Configuration |
Single phase, three loops |
||
|
Factor |
1.0 |
||
|
Insulation Class |
B |
||
|
Pole |
2 |
||
|
Phase |
1 |
||
|
Excitation Mode |
Self-excitation & constant voltage(AVR) |
||
|
Panel type |
General panel |
||
|
output |
socket |
2pc single phase socket |
|
|
|
Connection Pole |
Without |
|
|
|
DC12V Output |
Connection pole output |
|
|
Dimension ((L *W*H) |
750*500*660 |
||
|
Dry weight(kg) |
100 |
||
|
Working assorting weight (Kg) |
105 |
||
|
Noise level(7m)dB(A) |
97 |
||
|
Frame type |
Open frame |
||
Engine
|
Model |
GP 186FA |
|
|
Engine type |
Vertical,4 stroke, Air cooled, direct injection |
|
|
Displacement(mL) |
418 |
|
|
Cylinder NO.-bore×stroke (mm) |
1-86×72 |
|
|
Rated power(kW) |
5.7 |
6.3 |
|
Rated rotation speed(r/min) |
3000 |
3600 |
|
Fuel consumption ( g/kW.h) |
275.1 |
281.5 |
|
Capacity of Fuel Tank (L) |
15 |
|
|
Starting System |
Electric starter |
|
|
Compression ratio |
19:1 |
|
|
Continuous working hours(hr.) |
8 |
|
Product superiority:
- Economical fuel consumption system, to make sure excellent fuel atomization, effective combustion control and extremely low fuel consumption
- Low emission contamination
- Reliable power and tight compact structure
- Excellent loading response specification: high impact load, primary load exceeds 70%, perfect startup performance
- Easy to install and maintain
- Full storage of accessories and more than 4000 service networks worldwide
Our Service:
1. If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China. We can drive to pick you up and visit our factory.
2. Suggest the best choice or referential suggestion based on customers’ information. Answer all questions about the product from customer.
3. Build customers’ profiles, follow-up service, make regular calls on customers.
PHOTOS:
