CF20UU Brass Cage Track Industrial Roller Bearings OD 52MM Wear Resistant
CF20UU Brass Cage Track Industrial Roller Bearings OD 52MM Wear Resistant
1. Specification:
|
Specification of Bearing |
|
|
Bearing type |
Needle roller bearing/Track roller bearing |
|
Brand type |
INA,IKO,SKF,FAG,NSK and so on |
|
Precision Rating |
Germany and so on |
|
Vibration |
Z1V1,Z2V2,Z3V3 |
|
Durability |
Long |
|
Material |
Bearing steel |
|
Certificate |
ISO9001:2008 |
|
Main market abroad |
South America,USA,European,Southeast Asia,Middle East |
|
Packaging Details |
1. inner: polyester bag outer:paper carton 2. industrial standard packing 3. Poly bag+box+packing 4. 4. as your order |
|
Delivery Time |
Within 3-5 days after receiving your subscription |
|
Payment Terms |
T/T,Western Union,Paypal |
2. Feature:
(1) Stud type track roller
(2) Durable
(3) chrome steel
(4) brass,steel or nylon cage
(5) Good quality,competitive price
(6) Single packing box
3. Bearing Picture:
5. We aslo spply following spherical roller bearing
| Model | ID : | OD : | T(B) : |
| SHF25-6218A | 68mm | 110mm | 20.7mm |
| SHF32-8022A | 88mm | 142mm | 24.4mm |
| SHF40-9524A | 108mm | 170mm | 30mm |
| SHF50-12031A | 135mm | 214mm | 36mm |
| CSF14 | 9mm | 55mm | 16.5mm |
| CSF17 | 10mm | 62mm | 16.5mm |
| CSF20 | 14mm | 70mm | 16.5mm |
| CSF25 | 20mm | 85mm | 18.5mm |
| CSF32 | 26mm | 112mm | 22.5mm |
| CSF40 | 24mm | 126mm | 24mm |
| CSF50 | 32mm | 157mm | 31mm |
| CSF65 | 44mm | 210mm | 39mm |
| CSG14 | 9mm | 55mm | 16.5mm |
| CSG17 | 10mm | 62mm | 16.5mm |
| CSG20 | 14mm | 70mm | 16.5mm |
| CSG25 | 20mm | 85mm | 18.5mm |
| CSG32 | 26mm | 112mm | 22.5mm |
| CSG40 | 24mm | 126mm | 24mm |
| CSG50 | 32mm | 157mm | 31mm |
| CSG65 | 44mm | 210mm | 39mm |
| CSF14-3516 | 9mm | 55mm | 16.5mm |
| CSF17-4216 | 10mm | 62mm | 16.5mm |
| CSF20-5016 | 14mm | 70mm | 16.5mm |
| CSF25-6218 | 20mm | 85mm | 18.5mm |
| CSF32-8022 | 26mm | 112mm | 22.5mm |
| CSF40-9524 | 24mm | 126mm | 24mm |
| CSF50-12031 | 32mm | 157mm | 31mm |
| CSF65-16039 | 44mm | 210mm | 39mm |
| SHF14-3516A | 38mm | 70mm | 15.1mm |
| SHF17-4216A | 47mm | 80mm | 17mm |
| SHF20-5016A | 54mm | 90mm | 18.5mm |
What is a cam roller bearing?
A cam follower bearing is a roller or needle bearing that is specifically designed to follow cams or tracks. These bearings are used in linear motion systems including transfer lines, conveyor systems, and other industrial machinery.
What is the function of the cam roller?
A cam follower, also known as a track follower or a roller follower, is a rotating or oscillating component of an assembly that follows the motion of the translating cam through direct contact; it transforms the cam's reciprocating motions into a linear motion by moving vertically in relation to the cam's axis.
