CE ISO SGS Double Deck Car Parking System / 2.5T 2 Car Automotive Vehicle Lifts
Basement to Floor Double Platform Scissor Car Lift 2.5T 2 Car Park Scissor Lift:
Application:
- The Double Platform Scissor Car Lift can be used to lift car with different levels, suitable for car moving
between stairs, from basement to first floor, to second floor, or to third floor.
- Operation is easy. There are 2 sets control system installed on the Double Platform Scissor Car Lift,
1 control box below, and 1 hand controller on safety rail that can be operated on work platform.
The frequent models we supplied for our clients:
| MODEL | LOAD CAPACITY | PLATFORM SIZE | LIFT HEIGHT | PIT DEPTH | POWER |
| SJG2.5-3 | 2.5T | 5.2m x 2.6m | 3m | 750mm | 220V, 240V, 380V or 400V |
| SJG2-6.5 | 2T | 5.2m x 2.8m | 6.5m | 800mm | 220V, 240V, 380V or 400V |
| SJG2.5-3.5 | 2.5T | 5.2m x 2.6m | 3.5m | 800mm | 220V, 240V, 380V or 400V |
| SJG2.5-5 | 2.5T | 5.6m x 3m | 5m | 800mm | 220V, 240V, 380V or 400V |
| SJG3-2.5 | 3T | 5m x 2.3m | 2.5m | 750mm | 220V, 240V, 380V or 400V |
| SJG3-3 | 3T | 5.2m x 2.6m | 3m | 800mm | 220V, 240V, 380V or 400V |
| SJG3-3.5 | 3T | 5.6m x 2.7m | 3.5m | 800mm | 220V, 240V, 380V or 400V |
| SJG5-10 | 5T | 4.5m x 2.5m | 10m | 1150mm | 220V, 240V, 380V or 400V |
| SJG8-2.5 | 8T | 6.5m x 4.5m | 2.5m | 850mm | 220V, 240V, 380V or 400V |
| SJG12-3 | 12T | 5.5m x 2.8m | 3m | 950mm | 220V, 240V, 380V or 400V |
| SJG15-4.5 | 15T | 8m x 2.2m | 4.5m | 1150mm | 220V, 240V, 380V or 400V |
| SJG20-5 | 20T | 6m x 3m | 5m | 1200mm | 220V, 240V, 380V or 400V |
| The Double Platform Scissor Car Lift can be customized as your detailed size. | |||||
Parts showing:
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the cars above the platform.
3) The limit switch system helps Double Scissor Lift Table to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the Double Platform Scissor Car Lift are passed 1.2 times loading test before leaving factory.
The workshops:
The Spare Parts:
Drive Motor,Hydraulic system: 380V/5.5kw
High Precision Hydraulic Cylinder: 110*4sets;
Scissor material: 200mm*100mm*10mm high strength Manganese Steel.
Controller: 1 control box below, three buttons up down and stop, Very convenient and
simple; 1 control panel above platform
Platform Material: 120mm*60mm rectangular tube +6mm checkered iron
Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
Certificates:
Our services:
1) We can design the Double Platform Scissor Car Lift as per your requirement.
2) The most suitable Double Platform Scissor Car Lift will be recommended to you once we got your
requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty
time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) We could reply you in 2 hours after received your any questions even on weekend and
holiday.
Engineers are available to your country if necessary.
Welcome to visit our factory!
