1080P AHD IP69K Waterproof Wide Angle Dashcam Night Vision Car Dome Camera
1080P AHD IP69K Waterproof Wide Angle Dashcam Night Vision Car Dome Camera
-
Imaging Core:
▸ 1080P AHD architecture | Integrated Sony Starvis sensor
▸ Night vision 2.0 system (STARVIS 2 technology, 0.001Lux sensitivity threshold) -
Extreme Environment Protection:
• 6-layer optical coating (anti-fog/anti-glare/anti-static)
• Triple-protection housing (IP67 waterproof + 5G vibration resistance + EMI shielding) -
Intelligent Security Modules:
→ AI motion detection (3D digital noise reduction DSP)
→ Parking guard mode (low-voltage protection with auto power cycling)
→ Driving behavior analysis (ADAS lane departure warning support)
| Technical Parameters | |
| Image sensor | 1/2.9" CMOS |
| Horizontal resolution | 2.0Megapixel |
| TV system | PAL/NTSC |
| Effective pixel | 1920(H)*1080(V) |
| Minimum illumination | 0.05Lux@(F1.2,AGC ON) |
| S/N ratio | ≥56dB |
| Day/Night mode | Color |
| Sync system | Internal |
| Backlight compensation | AUTO |
| White balance | AUTO |
| Electronic shutter | AUTO/1/50(1/60)-1(50,000Sec) |
| Digital Noise Reduction | 2D-DNR,3D-DNR |
| Video output | AHD Standard,1080P output |
| Lens | 3.0mm |
| Viewing angle | H=120°,V=60° |
| IR leds Qty | 7pcs LEDs |
| IR distance | ≥5meters |
| Operating temp | -20°C~+70°C |
| Power supply | DC12V±10% |
| Power consumption | ≤1.5W |
FAQ:
1. Can you provide technical support?
Yes, we can provide professional technical support before and after sales.
2. What platform do you use?
We use CMSV6 platform. We will provide you the authorized code after you buy our equipment.
3. How can you guarantee the quality?
Strict quality control policy, 12 months warranty and Lifetime technical support. (Equipment maintenance is guaranteed during the shelf life)
4. Do you support ODM&OEM?
Yes, we can support ODM&OEM if you need.
5. How can i get a better price?
Tell us your specific needs and quickly match the right product for you, price are negotiable for bulky order.
