Electric Brass Hot Runner Spring Coil Heater Heating Element
Electric Brass Hot Runner Spring Coil Heater Heating Element
Description:
hot runner coil heater according with different sizes (the sprue bush or nozzle) design and manufacturing, the sleeve is made of high quality stainless steel or copper, inner sleeve, outer there are various winding section (round, square or flat) heating coil, temperature uniformity, thermal inertia characteristics, can be integrated with the K type, J type or E type control temperature thermocouple
Specification:
|
Minimum diameter Φ |
10mm |
|
Voltage |
12V- 400V |
|
Wattage tolerance |
±10% |
|
Material |
SS304/SS321/SS310/SS316 (Customized) |
|
Sleeve material |
Brass |
|
Resistance |
±10% |
|
Dielectric strength |
600V 800V 1000V |
|
Insulation(cold 1000V) |
>10 MΩ |
|
Leakage current(cold) |
<0.5mA |
|
Max power density |
10W/cm² |
|
Heating length tolerance |
±0.05mm |
|
Maximum working temperature allowed on sheath |
Max.750℃ / 1380°F |
|
Build-in Thermocouple |
Type K/ J/ E |
|
Standard supply 1000mm PTEE insulated nickel lead wire |
|
|
Material of lead wire:Fiberglass, Kevlar, Telfon, Silicone Rubber, Metal braided, SUS armoured. |
|
Application:
1.Injection molding machine nozzle
2. Hot Runner Nozzles & Bushings
3. Packaging machinery
4. Hot runner Injection Molds
5. Injection & Blow Moulding Machine Nozzles
6. PET preform & Thin wall container Moulds
7. Hot runner Manifolds
