High quality platinum MI thermocouple cable Mineral Insulated Type R in sheath material of inconel 600
High quality platinum MI thermocouple cable Mineral Insulated Type R in sheath material of inconel 600
Description:
Type R thermocouples are especially valued for their long service life and stability, performing exceptionally well in oxidizing or inert atmospheres. However, similar to type S thermocouples, they may experience drift when used over extended periods at high temperatures.
Due to these characteristics, Type R thermocouples find widespread use in industries that require precise temperature control, such as glass, ceramics, and metallurgy. They are also frequently used in laboratory settings and for calibrating other thermocouples, where their accuracy and stability are essential.
Features
Mineral Insulated Thermocouple Cable
Temperature range:-200-1300
MI cable: OD 0.25 - 8.00
Sheath material: Inconel 600, SS316, SS304, SS321.
Mini coil length: Per client's request
Accuracy: Class I, II
Wire: Simplex & duplex
Electric property:
Resistance value allowance:±10%
Dielectric property:heating cable pressure resist:1200V AC/1min
Insulation resistance:end product test:100MΩ/500VDC
Sheath continuity:all the heating cable submerged in the water 12 hours then test the insulation resistance,the value should be 50M/500VDC at least.
