Thermocouple Components Nitride Bonded Silicon Carbide NSiC Thermocouple Protection Tube

Price Negotiable

Price: Negotiation

MOQ: 50 pcs

Delivery Time: 10-15 working days after received your payment

Brand: GME

Product Description

Nitride Bonded Silicon Carbide RSiC Thermocouple Protection Tube

1. NSiC Thermocouple Protection Tube Brief Introduction

Nitride Bonded Silicon Carbide Thermocouple Protection Tubes have the excellent properties of high strength,

wide working temperature range, oxidization resistance and corrosion resistance. It can be widely used in the

thermometric system of nonferrous metal melting furnace.

2. NSiC Thermocouple Protection Tube Characteristics

3. NSiC Thermocouple Protection Tube Parameter.

Density g/cm3	Relative density	Elastic modulus GPa	Compression strength ratio25	Hardness GPa
3.26 0.02	>99.5	300320	4050	16 - 20
Fracture toughness /MPam1/2	Bending strength MPa	Poisson's ratio	Linear expansion coefficient 10-6K-1	Webuller modulus
6.09.0	9001000	0.25	3.13.3	1215
Thermal conductivity WmK-1	Specific resistance ratio	Corrosion resistance	Size stability	Magnetic
15~20	1018	Excellent	Excellent	NO

4.Thermocouple Ceramic Insulator Application

Furnace tube for resistance furnaces, heat treatment furnaces
Chemical analysis for steel and iron
Various insulationg parts for high temperature resistance and etching resistance
Temperature measuring meters
Protection and insulation for thermocouples and thermometers

5. Transportation
