OD 0.5mm S Type Noble Metal Thermocouple Wire For High Temperature
OD 0.5mm S Type Noble Metal Thermocouple Wire For High Temperature
1. Introduction
platinum/Rhodium wire
Type S thermocouples are characterized by a high degree of chemical inertness and stability at high temperatures. Often used as a standard for calibration of base metal thermocouples
Platinum rhodium thermocouple(S/B/R TYPE)
Platinum Rhodium Assembling Type Thermocouple is widely used in production places with high temperature. It is mainly used to measure temperature in glass and ceramic industry and industrial salting
Product Introduction
2. Parameter
| Conductor material | Type | Graduation | Spec. of protection tube(mm) | Use temperature°C | |||
| Total Lenght | Length in fluid | external diameter of ceramic tube | Material of protection tube | ||||
| PtRh10-Pt | WRP | S |
300 350 400 450 550 650 900 1150 1250 |
150 200 250 300 400 500 750 1000 1100 |
16 25 |
High Al content tube | 0-1300 |
| PtRh30-Ptrh6 | WRR | B | Corundum tube | 0-1600 | |||
| PtRh13-pT | WRQ | R |
16 20 |
High Al content tube | 0-1200 | ||
| Mini PtRh10-Pt | WRP-100 | S | 252 | 252 | 7 | High Al content tube | 0-1200 |
3. Advantage
- Fast thermal response
- High mechanical strength
- High measuring accuracy
- Long service lifetime
- Wide temp measuring range of -200-1300centigrade
4. Transportation
